Proliphix IMT350c Configuration Manual page 46

CHAPTER 2: Configuring the Thermostat Using the Web Interface
Table 2-7 Advanced Settings Fields - HVAC Field Descriptions
Field
HVAC System Type
If Your HVAC System is a Fuel Burner
Heat Control
Cool Control
If Your HVAC System is a Heat Pump
Reverse Valve Polarity
2-26
Beta Draft Confidential
Description
Select the type of HVAC system, either Fuel Burner (default) or
Heat Pump HVAC systems as follows:
Fuel Burner (default) – The HVAC system burns fossil
fuels (e.g. gas or oil). Typically the system includes either an
oil or gas fired boiler or furnace. See
page 2-24 and continue with
Burner (page
Heat Pump – Specifies that the HVAC system is based on
an electric compressor. See
continue with
2-26).
Select the HVAC control for this thermostat. This parameter
describes the thermostat capability to control a single stage or
dual stage heating system. The thermostat can also be disabled
from controlling a heating system and instead operate as a
cool-only thermostat.
Disable – No heating system exists. (A/C only thermostat.)
1H – Enables the heating system as a standard single stage
system.
Specify the HVAC control of this thermostat. This parameter
describes the thermostat's capability to control a single stage or
dual stage cooling system. The thermostat can also be disabled
from controlling a cooling system and instead operate as a
heat-only thermostat. (See
Disable – Specifies that there is no cooling system present.
(heat-only thermostat.)
1C – Enables the cooling system as a standard single stage
system.
Enables you to control the direction of the heating and cooling
modes.
O - Reverse for Cool – Indicates that the heat pump
normally runs in heat mode and when the reversing valve is
activated then the heat pump will run in cooling mode.
B - Reverse for Heat – Indicates that the heat pump
normally runs in cool mode and when the reversing valve is
activated then the heat pump will run in heating mode.
Internet Managed Thermostat Configuration Guide, Release 1.0
Figure 2-14 on
If Your HVAC System is a Fuel
2-26).
Figure 2-15 on page 2-25
If Your HVAC System is a Heat Pump (page
Heat Control (page 2-26).)
Part No. 600-03001-350, Rev. 1
and
