CHAPTER 2: Configuring the Thermostat Using the Web Interface
Table 2-3 Schedules-Daily Profile Definitions Field Descriptions (Continued)
Field
Fan Schedule
Default Weekly Schedule
In
Figure 2-3 on page
that you can use to apply the Profiles to each day of the week. The Web page applies
this weekly template to every week in each month that is visible in the Calendar
View at the bottom of the
To edit the Default Weekly Schedule, use the drop-down menu and select the
appropriate Profile.

Calendar

The Calendar View table displays the Profile settings for each day of the month.
2-10
Beta Draft Confidential
Description
Select the time in minutes for each hour of the Event in which the fan will be On.
The schedule begins on the hour and advances for the duration specified. Note that
within the hour of each Event but outside the schedule interval, the fan reverts to
AUTO mode to ensure proper operation for either a heating or cooling call to the
HVAC system. Select one of the following options:
Always Off
5 On / 15 Off
10 On / 10 Off
15 On / 5 Off
Always On
2-8, the Default Weekly Schedule table provides a template
Calendar (page 2-10)
Internet Managed Thermostat Configuration Guide, Release 1.0
page.
Part No. 600-03001-350, Rev. 1
