Use
Table 2-5 Alarms - Wired Sensors Field Descriptions
Field
RS1 and RS2
Low Temperature Limit
Present for
High Temperature Limit
Present for
Internet Managed Thermostat Configuration Guide, Release 1.0
Part No. 600-03001-350, Rev. 1
Table 2-5 to configure the Alarms - Wired Sensors page fields.
Description
Select a value or Disabled to indicate the low temperature
threshold detection status.
The value set by this parameter is monitored by the thermostat
and compared against the current Zone Temperature. If the
current Zone Temperature falls below this value, an alarm
condition is set and the status is displayed on the
2-2) page.
Disabled (default) – No low temperature limit is set.
° ° °
-30 F(-34.5 C) to 200 F(93
This is a major (red) alarm condition.
Enter how long the condition must be in effect before the alarm
is triggered. Note that the default is 0 minutes and the maximum
time allowed is 240 minutes.
Select a value or Disabled to indicate the high temperature
threshold detection status.
The value set by this parameter is monitored by the thermostat
and compared against the current Zone Temperature. If the
current Zone Temperature rises above this value, an alarm
condition is set and the status is displayed on the
2-2) page.
Disabled (default) – No high temperature limit is set.
° ° °
-30 F(-34.5 C) to 200 F(93
This is a major (red) alarm condition.
Enter how long the condition must be in effect before the alarm
is triggered. Note that the default is 0 minutes and the maximum
time allowed is 240 minutes.
Alarms Page
HVAC (page
°
C)
HVAC (page
°
C)
2-21
