Button Head Cap Screw 3/8"X 2 - Bowflex Revolution FT Assembly Instructions Manual


5
6
Only two needed for XP model.
Use 4 for FT model.
2
4
ITEM NO.
1
2
3
4
5
6
7
8
9
10
11
12
3
11
NOTE: When building the FT model you will have two left over 3/8" washers.
Hardware Card (Box 3)
QTY. DESCRIPTION
6

BUTTON HEAD CAP SCREW 3/8"x 2 3/4"

16 NARROW WASHER 3/8"
7 NYLOCK NUT 3/8"
2 BUTTON HEAD CAP SCREW WITH THREADLOCK 3/8"x 3/4"
5 BUTTON HEAD CAP SCREW WITH THREADLOCK 1/2"x 1"
9 NARROW WASHER 1/2"
1 BUTTON HEAD CAP SCREW 3/8"x 4"
2 NYLOCK NUT 1/2"
1 BUTTON HEAD CAP SCREW 1/2"x 4 1/2"
2 RUBBER PAD
4 CABLE HOOK
1 BUTTON HEAD CAP SCREW 1/2"x 4"
Hardware
10
2
1
12 7
9
2
6
3
8
