Tools You Will Need / Hardware Contents; Hardware Card (Box - Bowflex Revolution FT Assembly Instructions Manual

Hex Wrenches Are Provided in the Box
3/32" Allen Wrench for #8 Allen Screws
5/16" Allen Wrench for 1/2" Allen Screws
7/32" Allen Wrench for 3/8" Allen Screws
1/8" Allen Wrench for Top Cover Screws
3/16" Allen Wrench (used on XP model only)
NOTE: When building the FT model you will have 1 extra spring clip, two extra 1/2" plugs and two extra 3/8" plugs.
ITEM NO. QTY.
1 2
2 2
3 1
4 1
5 1
6 1
7 2
8 4
9 5
10 4
11 4
12 2
13 1
Tools You Will Need
Hardware Contents
12
2
10
11

Hardware Card (Box 2)

DESCRIPTION
BUTTON HEAD CAP SCREW WITH THREADLOCK 3/8"X3/4"
NYLOCK NUT 1/2"
WRENCH, ALLEN HEX 3/32"
WRENCH, ALLEN HEX 1/8"
WRENCH, ALLEN 7/32"
WRENCH, ALLEN HEX 5/16"
WASHER 3/8"
WASHER 1/2"
SPRING CLIP
1/2" PLASTIC PLUG
3/8" PLASTIC PLUG
BUTTON HEAD CAP SCREW 1/2"x3 1/4"
WRENCH, HEX 3/16"
These Tools Are Not Provided in the Box
Phillips Head Screwdriver
3/4" and 9/16" Wrenches or Adjustable Wrenches
* Tool and Hardware specifications subject to change
without notice.
8
7
1
3
4
13
6
5
9
