DVI•1000HD
Extends DVI up to 1640 feet (500 meters) over fiber optics cables.
The Gefen DVI-1000HD allows a single link video signal to be extended over long distances by
using multimode LC-LC fiber optic cable. Fiber Optics technology allows the DVI-1000HD to carry
video signals over long distances that would not be possible with traditional CAT5 extension. The
use of fiber optic cabling protects the video signal from electromagnetic interference (EMI) which
can degrade the video signal.
DVI•1000ST
How It Works
The DVI•1000HDS sender unit sits next to your computer, set-top box or DVD player source.
Cables supplied with the DVI•1000HD connect your DVI source to the send unit. The
DVI•1000HDR receive unit sits next to your DVI display - up to 1640 feet (330 feet HDCP) away.
The display plugs into the back of the DVI•1000HDR receiver unit. One CAT-5 cable and a multi
mode LC fiber optic cable (4 strand) connect the DVI•1000HDS and the DVI•1000HDR units to
each other.
Note: The DVI•1000HD is HDCP compatible.
DVI, HDCP, & HDMI Defined
Features:
Extends any DVI (digital visual interface) compliant device
up to 1640 feet/500 meters (330 feet with HDCP) from the computer
Uses a four-strand multimode LC-LC fiber optic cable for video signals
Uses one CAT-5 cable for DDC and control signals
Eliminates computer noise where you work
Supports resolutions up to 1080p, 2K, and 1920 x 1200
Supports DDWG standard for DVI compliant monitors
HDCP compliant

Specifications:

Video Amplifier Bandwidth: 165 MHz
Input Video Signal:1.2 volts p-p
Input DDC Signal: 5 volts p-p (TTL)
DVI Connector: DVI-D (19 pin) female
Video Link Connector: LC
DDC Link Connector: RJ-45 Shielded
Power Supply: 12V DC
Power Consumption: 36 watts (max)
Dimensions: 3.25" D x 4.25" W x 1" H
Shipping Weight: 5 lbs.
Rack mountable: 1U rack space
Package Includes:
DVI•1000HDS
DVI•1000HDR
One 12V Power Supply
One 6 ft DVI-SL cable (M-M)
User Manual
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46
http://www.meditronik.com.pl
e-mail: office@meditronik.com.pl
_
EXT-DVI-1000HD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXT-DVI-1000HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Gefen EXT-DVI-1000HD

  • Page 1: Specifications

    Extends DVI up to 1640 feet (500 meters) over fiber optics cables. The Gefen DVI-1000HD allows a single link video signal to be extended over long distances by using multimode LC-LC fiber optic cable. Fiber Optics technology allows the DVI-1000HD to carry video signals over long distances that would not be possible with traditional CAT5 extension.
  • Page 2 DVI • 1000HD U S E R M A N U A L www.gefen.com...
  • Page 3 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The DVI 1000 is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Introduction Front Panel Descriptions Back Panel Descriptions How To Connect The DVI 1000 How To Connect The DVI 1000 (w/o DDC) DVI 1000 Wiring Diagram Specifi cations Warranty...
  • Page 5: Operation Notes

    OPERATION NOTES READ THESE NOTES BEFORE IN STALL ING OR OPERATING THE DVI 1000 • The fi ber optics cable must be treated carefully when connectors are exposed. They are susceptible to dust which can contribute to loss of pixels. •...
  • Page 6: Introduction

    INTRODUCTION Thank you for purchasing Gefen’ s ex•tend•it DVI 1000. The DVI 1000 allows extension of DVI up to 1640 feet without losing any quality. CONTENTS The DVI 1000 consists of: (1) DVI 1000S (1) DVI 1000R (1) DVI cable (6FT)
  • Page 7: Front Panel Descriptions

    FRONT PANELS DESCRIPTIONS DVI 1000 Sender (Front View Only) Power LED indicates the unit is powered Clock Green HDCP & DDC Signals Blue Status LED indicates a link between the sender and receiver DVI 1000 Receiver (Front View Only) Power LED indicates the unit is powered Blue HDCP &...
  • Page 8: Back Panel Descriptions

    BACK PANELS DESCRIPTIONS DVI 1000 Sender (Rear View Only) 12 VDC Input DVI Input DVI 1000 Receiver (Rear View Only) 12 VDC Input DVI Output...
  • Page 9: How To Connect The Dvi 1000

    HOW TO CONNECT THE DVI 1000 Connect the DVI 1000 sender unit to the DVI source using the supplied cables. Connect the DVI 1000 receiver unit to your DVI display. Connect the four fi ber optics and one CAT5 cable between the sender and receiver. Plug the 12VDC power supplies into the DVI 1000 receiver.
  • Page 10: How To Connect The Dvi 1000 (W/O Ddc)

    HOW TO CONNECT THE DVI 1000 (w/o DDC) The DVI 1000HD can be hooked up without using the CAT5 if DDC is not needed. A second power supply will be required to power the receiver unit in this setup. For computer extensions where EDID is needed, a DVI Detective can be purchased to store the EDID of the display.
  • Page 11: Dvi 1000 Wiring Diagram

    DVI 1000 WIRING DIAGRAM...
  • Page 12: Specifi Cations

    SPECIFICATIONS Video Amplifi er Bandwidth ................. 1.65 GHz Input Video Signal ..................1.2 volts p-p Input DDC Signal ..................5 volts p-p (TTL) Single Link Range ..................1920 x 1200 DVI Input/Output Connector Type ................DVI-D Link Connector ......................RJ-45 Fiber Requirement ............
  • Page 13: Warranty

    Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
