1. Antenna
High efficency antenna.
2. TX LED indicator
This green LED Indicator is lighted when radio is in transmit mode.
3. SCAN / LOCK Key
SCAN
Shortly press the SCAN / LOCK (3) key to start the channels scanning (refer to AUTOMATIC CHANNEL SCANNING at
page 12).
KEYPAD LOCK
Press and hold the SCAN (3) key for about 5 seconds to enable the keypad LOCK function. Press and hold this key
again to disable the keypad LOCK function (refer to KEYPAD LOCK at page 12).
4. MON Key
Press the MON key (4) to activate the Monitor function. This function opens Squelch in order to listen to the background
noise and weak signals.
5. TALK / CALL Key
TALK
Press the TALK / CALL (5) key to transmit and hold it during transmission. The LED Indicator (2) will be lighted during
transmission. Release the TALK / CALL Key (5) at the end of your transmission to return to the receive mode.
WARNING ! Do not touch the antenna during transmission.
CALL
Press the TALK / CALL Key (5) twice in rapid action to transmit Call Tone.
6. Built-in Microphone
Built-in microphone.
7. Built-in Speaker
Built-in front speaker.
8. ON-OFF Key
Press and hold this key to switch ON or OFF the radio.
9. MENU Key
Press the MENU Key (9) key enable and program the various functions of the radio. Pressing the MENU Key (9) key
will scroll the various functions.
10. DOWN Key
The DOWN Key (10) is used to decrease the volume level (from level 8 to level 1) and toggle setting in Menu mode.
11. UP Key
The UP Key (11) is used to increase the volume level (from level 1 to level 8) and toggle setting in Menu mode.

12. LCD Display

The LCD Display indicates simultaneously all the programmed settings and all the enabled functions.

Controls and Indicators

- 4 -
