Status Window

The Status Window provides basic information pertaining to the installed drives and their
respective configuration:
1
2
Serial Number
1
System Status
2
Drive Status
3
Capacity Information
4

Elements of the Status window

System Status section
Temp : Indicates the current internal temperature of the SAT3550ESR Drive Enclosure
Fan Speed : Indicates the system fan status. Use this data to monitor possible
malfunctions
Drive Status section
Box Status : Indicates the drive status: Normal, Rebuilding, Unplugged, Needs
Drive S/N : Shows the unique serial number assigned by the disk manufacturer
Exp. S/N : Shows the expected serial number of the hard disk drive. The Daemon
compares the expected and actual drive serial numbers to detect when a
drive's status changes.
Instruction Manual
Rebuild, New Drive, Wrong Slot
6
3
4
