Torqeedo Cruise 2.0 R Operating Manual page 25

Display example in normal operation
when setup has not been completed:
Battery voltage (flashing
below 11.2 V per lead battery)
Can not be shown
Speed
Input power consumption
Other indicators:
Drive slowly: Is displayed if the battery capacity is < 50 % or if the voltage
falls below a value that could damage the battery.
No battery status: Is displayed if setup was not completed.
satellite signals to determine the position and speed. If no GPS signal
is received within 5 minutes, the remaining duration in the second field
from the top changes from distance to time information. In addition, a
clock icon is displayed. If the remaining duration is more than 10 hours it
is indicated in whole hours. If it is less it is shown in hours and minutes.
the central position (stop position). This is necessary for safety reasons
before starting off.
power independently.
Error: If an error occurs, the error icon and a two-digit code are dis-
played in the bottom field. The code shows the component causing the
error and the error itself. You will find details about the error codes in the
following table.
: The GPS module integrated into the shaft head searches for
: This icon is displayed if the remote throttle must be placed in
: Is displayed if the motor has overheated. The motor controls the
Display example in normal operation:
Battery charge (flashing
below 50 % of capacitiy)
Remaining range at
current speed
Speed
Input power consumption
Operating Manual Cruise 2.0 R / 4.0 R
9. Operation
25
