COMPLETE PARTS LIST
Item No.
89 Console cable 900MM
Washer ∮17
90
91 Cable 950mm
92 power wire 850mm
93 Front cover for upright tube
94 Rear cover for upright tube
95 Rear cover for swivel tube
96 Front cover for swivel tube
97 Top step foot cover
98 Bottom step foot cover
99 Pedal tube cover top L
100 Pedal tube cover bottom L
101 Pedal tube cover top R
102 Pedal tube cover bottom R
103 disc rim
104 Screw M4*12
105 bottle holder
106 power adapter
107 Screw M4*25
108 Cable 420MM
Washer ∮35*∮6*Ｔ2.0
109
Washer ∮17*∮12*Ｔ1.0
110
Washer ∮35*∮12*Ｔ2.0
111
112 Console bare
113A Left meter bare cover
113B Right meter bare cover
114 Front meter bare cover
115 Screw M4*16
116 Screw M3.5*12
117 Rear console bare cover
118A Left upright post cover
118B Right upright post cover
#A Washer M8
Description
www.smoothfitness.com
Qty.
1 CE25-89
2 CE25-90
1 CE25-91
1 CE25-92
1 CE25-93
1 CE25-94
2 CE25-95
2 CE25-96
2 CE25-97
2 CE25-98
1 CE25-99
1 CE25-100
1 CE25-101
1 CE25-102
2 CE25-103
4 CE25-104
1 CE25-105
1 CE25-106
2 CE25-107
1 CE25-108
1 CE25-109
3 CE25-110
1 CE25-111
1 CE25-112
1 CE25-113A
1 CE25-113B
1 CE25-114
4 CE25-115
6 CE25-116
1 CE25-117
1 CE25-118A
1 CE25-118B
CE25-#A
4
9
Part No.
