Assembly; Assembly Instructions - EcoWater ETF2100PF10 Owner's Manual

ECOWATER
S Y S T E M S
FILL THE MINERAL TANK
1. Remove the tank clamps, figure 1, valve assem-
bly, o--ring seals (3), and the top distributor.
2. Using a funnel, add the specified amount of filter
sand, then the mineral.
Note: The filter is factory filled with the correct
amount of gravel. Filter sand, and the desired filter
mineral are not included.
CAUTION: To prevent sand and mineral from enter-
ing the bottom distributor and riser, temporarily plug
with a clean rag.
FIGURE 1
valve

assembly

clamp section (2)
clamp retainer (2)
standpipe
o- -ring,
13/16"x 1- -1/16"
o- -ring,
2- -7/8"x 3- -1/4"
(thick)
resin
tank
o- -ring,
2- -3/4'x 3"
(thin)
top distributor
standpipe

Assembly Instructions

SANITIZING THE FILTER
Care is taken at the factory to keep you water filter
clean and sanitary. Materials used to make the filter
will not infect or contaminate your water supply, and
will not cause bacterial to form or grow. However, dur-
ing shipping, storage, installing and operating,
bacteria could get into the filter. For this reason, sani-
tizing, as follows, is suggested when installing.
Pour about 1 oz. (ETF2100PF10), or 2 oz.
(ETF2100PF12), of the following disinfectant into the
filter.
1. Calcium hypochlorite, available in granular or tablet
form, under trade names such as Perchloron or HTH.
2. Common 5.25% household bleach such as Clorox,
Linco, Bo Peep, White Sail, Eagle, etc.
NOTE - - ACTIVATED CARBON FILTERS: ACTI-
VATED CARBON WILL ABSORB THE SANITIZING
AGENT, EXPENDING SOME CAPACITY.
SANITIZING CONTINUED IN STEP 9, PAGE 10,
AND STEP 2 ON PAGE 12.
3. Thoroughly clean all sand and mineral from the
tank top opening. Then, install the top distributor
and o--ring seals (4), exactly as shown in figure 1.
4. Lower the valve assembly, onto the mineral tank,
centering over the standpipe, Push downward, to
squeeze the o--rings, and install the clamp sections
and both retainers. BE SURE THE CLAMPS AND
RETAINERS ARE FIRMLY IN PLACE.
5
3
