Phone Screen Features

This is what your Cisco IP Communicator phone screen might look like with a call active and several
feature menus open. You can click screen items to select or activate them.
Primary line
1
Line area
2
Speed dial area
3
4 Softkey labels
Status line
5
Call activity area
6
Phone tab
7
Feature tabs
8
Related topics
• Using the Cisco IP Communicator Interface, page 10
• Call-Handling and Navigation Tips, page 15
14
Displays your primary extension number and the time and date. If several
tabs are open, the time and date alternate with the extension number.
Displays your extension number(s). Each extension represents a phone line
and corresponds to a
Displays speed dial labels. Each label corresponds to a speed dial button.
See the "Setting Up Speed Dial Buttons" section on page 33.
Each displays a softkey function. Activate a softkey by clicking the softkey
label or the button below the label.
Displays status information and user prompts.
Displays currently active calls, including caller ID, call duration, and
call-state icons. You can click an active call to select it.
Appears when there is call activity. Click this tab to return to the call
activity area from another screen.
Each indicates an open feature menu. Feature tabs appear after you open a
feature by clicking the corresponding feature button:
, ,
(line button).
, , or .
