extronics iSCAN100 Operating Manual page 9

Intrinsically safe barcode scanner
Table of Contents

Advertisement

The iSOLATE100 Ex03 mode allows one keyboard and or one RS-232 scanner
device in the EEx i area. The scanner must be connected to one of the mouse
terminals at the hazardous side, this is still the case even if there is no keyboard.
PS/2 and screw terminals for the hazardous area are wired in parallel.
Description
TxD
Rxd
GND
+5V Supply
iSCAN100 RS232 Cable Connection Details
Core Colour
Green
Yellow
White
Brown
9
