Audible Indicators - extronics iSCAN100 Operating Manual

When the iSCAN100 is in operation, it provides audible feedback. These sounds
indicate the status of the scanner. Eight settings are available for the tone of the
beep (normal, 6 alternate tones and no tone). To change the tone, refer to the
®
MetroSelect Single-Line Programming Guide
Alternatively see the help files contained in the
One Beep
When the scanner first receives power, the green LED will turn on, then the red
LED will flash and the scanner will beep once. (The red LED will remain on for
the duration of the beep.) The scanner is ready to scan.
When the scanner successfully reads a bar code, the red LED will flash and the
scanner beeps once (if programmed to do so). If the scanner does not beep once
and the green light does not flash, then the bar code has not been successfully
read.
Two Beeps — On Power Up
When there is a Flash ROM upgrade needed, the scanner will beep twice
followed by alternating flashing of the green and red LEDs.
Three Beeps - During Operation
When entering configuration mode, the red LED will flash while the scanner
simultaneously beeps three times. The red and green LEDs will continue to flash
while in this mode. Upon exiting configuration mode, the scanner will beep three
times, and the LEDs will stop flashing.
When configured, 3 beeps can also indicate a communications time-out
during normal scanning mode.
When using one-code-programming, the scanner will beep three times (the
current selected tone), followed by a short pause then by a high tone and a low
tone. This tells the user that the single configuration bar code has successfully
configured the scanner.
Raspberry Tone\Three Beeps - On Power Up
This is a failure indicator. Refer to "Failure Modes" on page 14.

4.2 Audible Indicators

included with the scanner.
MetroSet
®
2 help files.
15
