Connecting the Transducer

WARNING
Keep all plugs and sockets absolutely dry at all times.
The transducer is connected to the scanner using the array Transducer Socket on the
scanner. To connect, the transducer plug's locking lever should first be in a horizontal
position. Align the plug to the scanner socket and insert securely. Turn the locking lever
clockwise to lock in place.
When the transducer is attached to the scanner, the diode light is orange.
When connected the transducer complies with Type B requirements of EN60601-1 (IEC
60601-1).

Changing Frequency

The Multi-Frequency Imaging (MFI) facility enables you to select the scanning frequency.
See the applicable scanner user guide for instructions. The selected frequency is displayed
at the top of the screen.

Using a Transducer Cover

The transducer should be enclosed in a transducer cover or a standard condom. See the
Product Data sheet for a list of available transducer covers.
WARNING
Because of reports of severe allergic reactions to medical devices containing latex (natural
rubber), FDA is advising health-care professionals to identify their latex-sensitive patients
and be prepared to treat allergic reactions promptly.
Apply gel to the tip of the transducer. This improves the screen images by preventing image
artifacts caused by air bubbles.
Pull the transducer cover over the transducer.
Gel also creates a good acoustic contact between the skin and the transducer; therefore,
apply a small amount to the outside of the cover prior to scanning. Re-apply the gel
frequently to ensure good screen images.
WARNING
Use only water-soluble agents or gels. Petroleum or mineral oil-based materials may harm
the cover material.

Using the Transducer Control Button

The transducer has a control button that you can press to Start or Stop scanning (freeze
frame). Press the button for more than one second to make a copy of the image.
Note: Transducer buttons cannot be used to copy images using the Mini Focus 1402
Ultrasound Scanner.
Each time the button is pressed, a "beep" is emitted.
When the transducer is scanning, the diode light is green. When scanning stops, the light is
orange.
