Advantech PCA-6289 User Manual

Advantech PCA-6289 User Manual

Socket 604 dual xeon /lv xeon full-sized processor card with pci-x/ddr/vga/ dual gbe/400 or 533 mhz fsb
Hide thumbs Also See for PCA-6289:
Table of Contents

Advertisement

Quick Links

Download this manual
PCA-6289
Socket 604 Dual Xeon™/LV
Xeon™ Full-sized Processor
Card with PCI-X/DDR/VGA/
Dual GbE/400 or 533 MHz FSB
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCA-6289 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PCA-6289

Summary of Contents for Advantech PCA-6289

  • Page 1 PCA-6289 Socket 604 Dual Xeon™/LV Xeon™ Full-sized Processor Card with PCI-X/DDR/VGA/ Dual GbE/400 or 533 MHz FSB User’s Manual...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted, 2005, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 Advantech equipment is destined for the laboratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known. Your satisfaction is our primary concern. Here is a guide to Advantech’s customer services.

  • Page 4: Product Warranty

    Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 5: Initial Inspection

    It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCA-6289, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifica- tions, notify our service department or your local sales representative immediately.

  • Page 6: Important Safety Information

    Important Safety Information SAFETY INSTRUCTIONS This device complies with the requirements in part 15 of the FCC rules: Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Table Of Contents

    Mechanical and environmental specifications ....4 Jumpers and Connectors............ 5 Table 1.1:Jumpers ............5 PCA-6289 Block Diagram ..........8 Figure 1.2:PCA-6289 Block Diagram ......8 Safety Precautions ............9 Jumper Settings ............... 10 1.8.1 How to set jumpers ............10 System Memory ..............
  • Page 8 Resources Controlled By ..........26 2.7.3 PCI/VGA Palette Snoop ..........26 2.7.4 PCI Latency Timer (CLK) ........... 26 PC Health Status.............. 27 Figure 2.8:BIOS- PC Health Status ......27 Load Fail-Safe Defaults ..........27 2.10 Load Optimized Defaults ..........27 PCA-6289 User Manual viii...
  • Page 9 2.11 Set Supervisor/User Password ........28 2.12 Save & Exit Setup ............28 2.13 Exit Without Saving ............28 Chapter 3 VGA Setup ............. 30 Before you begin ............. 30 Installing VGA Driver............. 31 Figure 3.1:Installing VGA Driver ........ 31 Chapter 4 Chipset Software Installation Utility ...
  • Page 10 PCA-6289 User Manual...
  • Page 11 General Information...

  • Page 12: Chapter 1 Hardware Configuration

    PICMG 1.0 specification and meets most requirements for industrial applications. The PCA-6289 uses Intel's E7501 chipset to support dual Intel Socket 604 Xeon™/ LV Xeon™ processors with 533/400 MHz front side bus. The dual channel DDR 200/266 SDRAM interface provides bottle neck free memory bandwidth up to 4.2 GB/s.

  • Page 13: Specifications

    Supports Hyper-Threading : This allows HT-enabled Xeon™ / LV Xeon™ processors to process two threads simultaneously. By building two logical processors into a single physical processor, the performance and utilization of the processor resource will both increase. Users can obtain a higher CPU performance while Hyper- Threading is enabled.

  • Page 14: Vga Interface

    • Power consumption: Typical : +5V @ 10A, +12V @ 13.5A (Intel Xeon 3.06G CPU) or +5V @ 8.5A, +12V @ 7.5A (Intel LV Xeon 2.4G CPU). • Board size: 338.58 mm (L) x 122 mm (W) (13.3" x 4.8"). PCA-6289 User’s Manual...

  • Page 15: Jumpers And Connectors

    1.4 Jumpers and Connectors Connectors on the PCA-6289 single board computer link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application.
  • Page 16 Table 1.2: Connectors on PCA-6289 IO board Label Function Primary IDE connector Secondary IDE connector PIO connector Floppy Disk connector J3, J4 SIO connector J8, J9 Single USB connectors Dual USB pin headers for front USB interface PCA-6289 User’s Manual...
  • Page 17 1.5 Board Layout: Jumper and Connector Locations Figure 1.1: Jumper and Connector locations...

  • Page 18: Pca-6289 Block Diagram

    Backplane 64-bit/66MHz PCI-X PCI to ISA DMA 33/66/100 Bridge 2 ATA 100 ITE IT8888 ports 4 USB Ports ICH3-S Audio Codec AC-97 2.0 ATi Rage XL LPC Bus Super I/O BIOS IT8712 Figure 1.2: PCA-6289 Block Diagram PCA-6289 User’s Manual...

  • Page 19: Safety Precautions

    Notice: Before install your PCA-6289 into a chassis, make sure that all components on both sides of the CPU card do not touch any metal parts, especially the chassis wall and add-on card at...

  • Page 20: Jumper Settings

    SHORT. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is Short (on) Open (off) OPEN. These illustrations show a 3-pin jumper. Pins 1 and 2 are SHORT. PCA-6289 User’s Manual...

  • Page 21: System Memory

    Bank 0 and 1, corresponding to connector DIMM1, DIMM2. The table below shows possible DIMM configurations for the memory banks. Please be noted that the PCA-6289 supports 8 GB DDR SDRAM. Configurations using different brands of memory modules are not recom- mended.

  • Page 22: Memory Installation Procedures

    Make sure the pins of the CPU fit evenly to the socket openings. Replace the handling bar to fasten the CPU to the socket. Figure 1.3: Processor Installation PCA-6289 User’s Manual...
  • Page 23 Table 1.5: Installing the heatsink Step 1 Insert the fan in the CPU bed. Step 2 As shown in the picture, screw tight Step 3 Then get the fan connector connected.
  • Page 24 PCA-6289 User’s Manual...
  • Page 25 Award BIOS Setup Chapter 2...

  • Page 26: Chapter 2 Award Bios Setup

    Choose the “Standard CMOS Features” option from the “Initial Setup Screen” menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. PCA-6289 User’s Manual...

  • Page 27: Figure 2.2:Standard Cmos Features Screen

    The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the PCA-6289 according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 28: Figure 2.3:Advanced Bios Features Screen

    2.4.6 First/Second/Third Boot Device The BIOS tries to load the OS with the devices in the sequence selected. Choices are: "Floppy", "LS120", "HDD-0", "SCSI", "CDROM", "HDD- 1", "HDD-2", "HDD-3", "ZIP100", "USB-FDD", "USB-ZIP", "USB- CDROM", "USB-HDD", "LAN", "Disabled". PCA-6289 User’s Manual...

  • Page 29: Boot Other Device

    2.4.7 Boot Other Device To boot another device, choose "Enabled" or "Disabled". 2.4.8 Swap Floppy Drive If the system has two floppy drives, choose "Enabled" to assign physical drive B to logical drive A and vice-versa. The commands are “Enabled” or “Disabled.”...

  • Page 30: Apic Mode

    Figure 2.4: Advanced chipset features screen 2.5.1 System BIOS Cacheable BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result. The available choices are Enabled, Disabled. PCA-6289 User’s Manual...

  • Page 31: Video Bios Cacheable

    2.5.2 Video BIOS Cacheable Selecting Enabled allows caching of the video BIOS ROM at C0000h, resulting in better video performance. However, if any program writes to this memory area, a system error may result. The choices : Enabled, Dis- abled. 2.5.3 Memory Hole at 15M-16M In order to improve performance, certain space in memory is reserved for ISA cards.

  • Page 32: On-Chip Ide Device

    I/O port or IRQ for it. You can also disable this serial port if you do not need to use it. Doing so frees up the I/O port and IRQ used by this serial port. Those resources can then be reallocated for other devices to use. PCA-6289 User’s Manual...

  • Page 33: Onboard Parallel Port

    2.6.9 Onboard Parallel Port This feature allows you to select the I/O address and IRQ for the onboard parallel port. The default I/O address of 387h and IRQ of 7 should work well in most cases. Unless you have a problem with the parallel port, you should leave it at the default settings.

  • Page 34: Power Supply Type

    2.6.18 Suspend Type Select the Suspend Type. The Choices: PwrON Suspend, Stop Grant. 2.6.19 MODEM Use IRQ This determines the IRQ in which the MODEM can use. The Choices: 3, 4, 5, 7, 9, 10, 11, NA. PCA-6289 User’s Manual...

  • Page 35: Soft-Off By Pwrbtn (Power Button)

    2.6.20 Soft-Off by PWRBTN (Power Button) Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system “hangs”. The available choices are Delay 4 Seconds, Instant Off. 2.6.21 Wake up on LAN 1 When the system enters a Soft-off mode (Standby power exists but sys- tem is not working), it will wake up system when specific signals occurred.

  • Page 36: Pnp/Pci Configurations

    The Choice: Auto (ESCD), Manual. 2.7.3 PCI/VGA Palette Snoop Leave this field at Disabled. The Choices: Enabled, Disabled. 2.7.4 PCI Latency Timer (CLK) This item controls how long each PCI device can hold the bus before another takes over. PCA-6289 User’s Manual...

  • Page 37: Pc Health Status

    2.8 PC Health Status Figure 2.8: BIOS- PC Health Status After you have read the PC Health Status, press the <ESC> key to go back to the main program screen. 2.9 Load Fail-Safe Defaults This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the whole setup utility.

  • Page 38: Pca-6289 User Manual

    This record is required for the system to operate. 2.13 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. PCA-6289 User’s Manual...
  • Page 39 VGA Setup Chapter 3...

  • Page 40: Chapter 3 Vga Setup

    Chapter 3 VGA Setup 3.1 Before you begin The PCA-6289 series comes with a driver installation CD-ROM that enables you to install VGA driver software, Intel chipset software, and LAN. PCA-6289 User’s Manual...

  • Page 41: Installing Vga Driver

    3.2 Installing VGA Driver Figure 3.1: Installing VGA Driver Step 1 Double click the folder of VGA. The menu will display. Select the folder of J5.30.0_CD09_ RXL_N-WDM for Windows 2000 operating system. Step 2 After the menu dis- plays, select the SETUP icon.
  • Page 42 Select "Yes, I want to restart my computer now," and then click Finish. After your computer reboots, VGA driver is already setup in your computer. PCA-6289 User’s Manual...
  • Page 43 Chipset Software Installation Utility Chapter 4...

  • Page 44: Chapter 4 Chipset Software Installation Utility

    Chapter 4 Chipset Software Installation Utility 4.1 Installing Intel Chipset Software Step 1 Open the folder of Intel Chipset software Step 2 Double click the blue icon infinst_autol PCA-6289 User’s Manual...
  • Page 45 Step 3 Click Next to install INF. Step 4 Click Yes to con- tinue Step 5 Click NEXT Chapter 4...
  • Page 46 Step 6 Select Yes, I want to restart my computer now. Then click Finish. INF is installed. Step 7 Click Yes to con- tinue. Step 8 Click NEXT PCA-6289 User’s Manual...
  • Page 47 Step 9 Select Yes, I want to restart my computer now. Then click Finish. INF is installed. Chapter 4...
  • Page 48 PCA-6289 User’s Manual...
  • Page 49 LAN Configuration Chapter 5...

  • Page 50: Chapter 5 Lan Configuration

    Chapter 5 LAN Configuration 5.1 Installation Step 1 After the folder of LAN driver dis- plays, click it. Step 2 Double click the Autorun Icon Step 3 Click Install Base Driver. PCA-6289 User’s Manual...
  • Page 51 Step 4 Click OK to con- tinue Step 5 Click NEXT to continue Step 6 Click NEXT after accepting the license agree- ment. Chapter 5...
  • Page 52 PCA-6289 User’s Manual...
  • Page 53 USB 1.1 Configuration Chapter 6...

  • Page 54: Chapter 6 Usb 1.1 Configuration

    Chapter 6 USB 1.1 Configuration 6.1 Installation Step 1 Choose the setup type that best suits your needs and then click NEXT. Step 2 Click INSTALL to begin installation. Step 3 Click FINISH to exit after the instal- lation. PCA-6289User’s Manual...
  • Page 55 Programming the Watchdog Timer Appendix A...

  • Page 56: Appendix A Programming The Watchdog

    Appendix A Programming the watchdog A.1 Programming the Watchdog Timer The PCA-6289's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer and how to program it.

  • Page 57: Table A.2:Wdt Control Register Bit Definition

    Table A.2: WDT Control Register Bit Definition A.1.3 Watchdog Timer Programming Procedure Power On or Reset the System The initial value of WDT Control Register (D3~D0) is zero (0), when power is on or the system has been reset. The following table indicates the initial value of WDT (00000000b ) Table A.3: WDT Control Register Initial Value Value...
  • Page 58 1. Select the time-out intervals of WDT (decide the values of D2, D1, D0 in F2 ) Example: If D2~D0 = 0, the time-out interval is 64 seconds. 2. Enable or Disable WDT ( decide D3 value in F2) i.e. D3=0, Disables WDT i.e. D3=1, Enables WDT PCA-6289 User’s Manual...
  • Page 59 After finishing the above settings, you must output the Control Register’s value to WDT Configuration Port. Then WDT will start according to the above settings. GPIO User's Guide Digital I/O UESD Port 801 Appendix A...
  • Page 60 PCA-6289 User’s Manual...
  • Page 61 I/O Pin Assignments Appendix B...

  • Page 62: Appendix B Pin Assignments

    • J8: Keyboard & Mouse Mini Din Description Description KBDATA- MOUSEDATA KBCLK MOUSECLK • J9, J10: LAN RJ45 Connector Description Description TXD_0P TXD_0N TXD_1P TXD_2P TXD_2N TXD_1N TXD_3P TXD_3N SPEED_LED +VSBY3.3 LINK_LED ACTIVE_LED PD to TERMPLANE PD to TERMPLANE * PD means Pull-Down PCA-6289 User’s Manual...

  • Page 63: Daughterboard

    B.2 Daughterboard • J1: 2x13 2.0mm Box Header for PIO Connector Description Description STB- PD-4 ACK- BUSY SLCT AFD- ERR- INIT- SLIN- • J2: Floppy Disk Connector Description Description REDWC# INDEX# MOTSA# DRVSB# DRVSA# MOTEB# DIR# STEP# WDATA# WGATE# TK00# WPT# RDATA# SIDE1#...

  • Page 64: Pin Description

    GND (Chassis Ground) • J5: ATX Power Connector (Daughterboard) Description Description PS_ON# +5Vsb • J6: AC’97 Connector Description Description SDATOUT VCC5V SYNC VCC12V SDATAIN0 SDATAIN1 BITCLK • J7: 1x2 2.54mm Pin Header for IDE LED Description Description IDE_LED PCA-6289 User’s Manual...
  • Page 65 • J8, J9: USB Single Upright Right-Angle Connector Description Description USBP0 minus USBP0 plus • J12: Dual USB pin header for front USB interface Description Description USBV0 USBV0 USBD0- USBD1- USBD0+ USBD1+ • J13: 1x3 2.54mm Pin Header for AT/ATX Selection Description * 1, 2 Short ATX Mode...
  • Page 66 Data 8 Data 6 Data 9 Data 5 Data 10 Data 4 Data 11 Data 3 Data 12 Data 2 Data 13 Data 1 Data 14 Data 0 Data 15 DMA REQ IOCHRDY Pull Down DMA ACK PCA-6289 User’s Manual...
  • Page 67 Interrupt 14 Disk Address 1 DMA66 Detect Disk Address 0 Disk Address 2 HDC CS100 HDC CS300 HDD Active LED • CON2: IDE (Secondary) Connector Description Description Reset # Data 7 Data 8 Data 6 Data 9 Data 5 Data 10 Data 4 Data 11 Data 3...
  • Page 68 PCA-6289 User’s Manual...
