Page 1: User Manual
PTN Electronics SC91DM Scaler Switcher, with Digital Amplifier User Manual SC Series --- Presentation Scaler Switcher Please read this manual carefully before using this product. -
Page 2: Table Of Contents
SC91DM Presentation Scaler Switcher Content table 1. Function ..............................5 2. Features ..............................5 3. Front Panel .............................. 6 4. Real Panel ............................... 7 Specification ............................8 Description for Video/Audio Parts ....................... 9 IR Remote Description ........................12 System Diagram........................... 13 RS232 Control Command Introduction ................... - Page 3 Please refer to the dealers for the latest details. This manual is copyright PTN Electronics Limited. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited.
-
Page 4: Operation Notice
SC91DM Presentation Scaler Switcher Operation Notice In order to ensure the credibility use of the product and the user’s safety, please comply with the following items during installation and maintenance: The system must be earthed properly. Please do not use two blades plugs and ensure the alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz. -
Page 5: Function
SC91DM Presentation Scaler Switcher 1. Function SC91DM is the Full-HD scaling presentation switcher with digital amplifier, scaling 10 video inputs including 2 HDMI, 2 VGA, 2 component video, 2 composite video, 1 separate video up to 2 outputs at HDMI and VGA simultaneously, supporting HDTV, controllable via IR remote, front panel &... -
Page 6: Front Panel
SC91DM Presentation Scaler Switcher supporting the video preset function (news, entertainment, music, cinema. ) ·High-Class windows setting(Trint, Phase, Frequency, H/V position, color space ) ·High-class volume setting (bass, treble, balance, sound mode), audio mode preset. ·Stand by setting, duration time setting. Stand by setting. -
Page 7: Real Panel
SC91DM Presentation Scaler Switcher user can see all his operation from the displayer. IR Sensor 4. Real Panel 2 VGA connectors inputs. 2 HDMI connectors inputs (2 separated audio , 3.5mm mini. jack) 2 YPbPr (3 pcs RCA )connectors inputs... -
Page 8: Specification
SC91DM Presentation Scaler Switcher 5. Specification VIDEO/DISPLAY Specification Video Input Video Output 2 HDMI 2 Computer Graphics picture 1 HDMI Input 2 component video Output 1 Computer Graphics 2 composite video 1 S-video HDMI female connector VGA (15 pin HD),... -
Page 9: Description For Video/Audio Parts
SC91DM Presentation Scaler Switcher 8 RCA for for Composite video & Super audio Input Connector Output Connector 2 RCA for line audio 4 3.5mm for VGA audio 3 Mono Audio for MIC audio Audio Input Audio Output >10Ω 50Ω Impedance... - Page 10 SC91DM Presentation Scaler Switcher 1280×720P 16:9 1280×720P 37.50 16:9 1920×1080 I 1125 28.125 16:9 1920×1080 I 1125 33.75 16:9 1920×1080 I 1250 31.25 16:9 1920×1080 p 1250 62.5 16:9 1920×1080 p 1250 67.5 16:9 PS: the band width can achieve 170MHz multiplicity SCALER Mode（auto，normal，wide，fill all，Anamorphic，zoom etc）;...
- Page 11 SC91DM Presentation Scaler Switcher 1920×1080P 60 HZ DVI input compatible； Auto detect HDMI（DVI）Color Space; Digital audio decoding； multiplicity SCALER Mode（4:3; FILL ALL etc）; Only one HDMI port can be used at the same time; Part 4: Audio Input/Output Integrated SGTV5810/5830，support 2 channels audio output ;...
-
Page 12: Ir Remote Description
SC91DM Presentation Scaler Switcher 7. IR Remote Description IR remote is the default accessory, going with the SC91DM. It is working with the CR battery. It can control various functions, such as switching, resolution changing, volume function and OSD function. -
Page 13: System Diagram
HDCP protection signal, which can only be switched to the HDMI output. And, the SC91DM has 7 audio inputs, including the 4x 3.5mm jack, 3x RCA. Every audio input can be switching following the video or break away switching by RS232 controlling. -
Page 14: Rs232 Control Command Introduction
SC91DM Presentation Scaler Switcher 9. RS232 Control Command Introduction Communication protocol: Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Command Command Type Command Description Input selection, and output resolution selection. [XX] is for input source selection. - Page 15 SC91DM Presentation Scaler Switcher Command Command Type Command Description 0720% Get the current status of the brightness, contrast, color hue, saturation, phase and sharpness 0721% Screen Saver Color Black 0722% Screen Saver Color Blue 0723% Disable on screen display status of video source name which is shown in the right bottom of the screen.
- Page 16 SC91DM Presentation Scaler Switcher Command Command Description Type Command ENTER 0609% move left of the menu 0609% Menu move right of the menu 0610% Operation 0611% Move up of the menu Move Down of the menu 0612% 0600% MUTE for Line Vol and MIC Vol...
-
Page 17: Troubleshooting & Maintenance
SC91DM Presentation Scaler Switcher 10. Troubleshooting & Maintenance 1. When images of terminal unit output with ghost, such as the projector output with ghost, please check the projector’s setting or try another high quality connection cord. 2. When there is a color losing or no video signal output, please check the input and output end connection of cable.
