Intek M-100 PLUS Owner's Manual page 5

Man. M-100 PLUS UK_ITA
LCD Display
A. Channel Number
It indicates the operating channel number or the frequency band ID code.
B. ALPHA Icon
The ALPHA Icon (B) is lighted when an intermediate channel is selected.
This feature is not available on the radios for the European Market.
C. LO Icon
The LO Icon (C) is lighted when the transmitter is in LOW POWER mode (1W).
D. HI Icon
The HI Icon (D) is lighted when the transmitter is in HIGH POWER mode (4W).
E. ANL Icon
The ANL Icon (E) is lighted when the ANL (Automatic Noise Limiter) function is enabled.
F. FM Icon
The FM icon (F) is lighted when radio has been set to the FM (Frequency Modulation) operating mode.
G. AM Icon
The AM icon (G) is lighted when radio has been set to the AM (Amplitude Modulation) operating mode.
5. DN (Down) Key
This key allows to select the operating channel downward. By keeping this key pressed, the quick channel selection
mode will be enabled.
6. UP (Up) Key
This key allows to select the operating channel upward. By keeping this key pressed, the quick channel selection mode
will be enabled.
7. TX Indicator
This red color LED indicator is lighted when radio is in the transmit mode.
8-10-2008 15:00 Pagina 5
Controls, Indicators and operation
A
G
AM FM ANL
F E
- 3 -
B
HILO ALPHA
D C
