ATIS Function - Specifications - Optional Accessories
ATIS Function (Automatic Transmission Identification System)
The ATIS system is used in some countries to identify boats navigating in internal waterways. To use ATIS a boat must
be first given an ID number from the local authority. This is a 10-digit number always starting with 9. Once the ID number
is available, it must be stored in the radio, using the optional programming software (INTEK CDMR-8050). Radio will run
an ATIS test anytime it is switched on. If an ATIS code has been stored, the ATIS function will be automatically enabled
and the ATIS icon (E) will appear on the LCD. Check local regulations before using the ATIS function.

SPECIFICATIONS

General
Channels
Operating Frequency
Power Source
Dimensions
Weight
Receiver
Sensitivity
Audio output
Adjacent channel
Transmitter
Output Power
Modulation

Optional Accessories :

CDMR-8050 PC interface cable and software CD
INTERNATIONAL / USA / CANADA / METEO
156.025 - 157.425 MHz (TX)
156.300 - 162.000 MHz (RX)
9.0V (6 x AA 1.5V alkaline battery)
7.2V (6 x AA 1.2V rechargeable battery)
H146 x L66 X D38 mm (main body)
gr. 370 (including battery)
0.3µV for 12dB SINAD
0.5W at 8 ohm
60dB
1W-2W-5W selectable
FM
- 11 -
