- Page 1 User Manual 8x8 VGA Matrix Switcher over CAT5 with Stereo Audio AT-VGA88M-SR Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
-
Page 2: Table Of Contents
7.1. Power Off Mode ..........7 7.2. Front Panel Lock ..........8 7.3. Unit Reset ..........8 8. Connection Diagram ..........9 9. Safety Information ..........10 10. Warranty ..........11 11. Atlona Product Registration ..........12 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
Atlona Technologies’ AT-VGA88M-SR is one of the most innovative VGA Matrix Switchers with Stereo Audio on the market. The AT-VGA88M-SR has 8 individual VGA (RGBHV) inputs with Stereo Audio and 8 individual CAT5 outputs. The matrix switch can route any input to any output. This unit is ideal forconnecting sources such as computer, Set Top Boxes, and Satellite Receivers to desired displays over CAT5 cable such as HDTV, LCDs, Plasma Monitors, and Video Projectors. -
Page 4: Specification
SPECIFICATIONS RECEIVER UNIT SPECIFICATIONS Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 5: Panel Descriptions
6. 19 INCH RACK MOUNT BRACKETS: 19 inch 2U 2. Rear Panel 1.DC POWER INPUT. Power Jack: DC Jack - inner OD O 2.1mm (+ ) Outside OD O 5.5mm (GND) Power input - 12V DC, 3A Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... - Page 6 - Stereo Audio, 1x 3.5mm ear phone jack 7. CAT5 OUTPUTS (VGA+AUDIO) Extend VGA (RGBHV) signal thru CAT5 cable to VGA displays including audio. Output 1~8 CAT5 port signals: - CAT5 VGA (RGBHV) + Audio Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
-
Page 7: Remote Control
INPUT#3 / OUTPUT#3 : 03FC 33CC INPUT#3 / OUTPUT#4 : 03FC 34CB INPUT#3 / OUTPUT#5 : 03FC 35CA INPUT#3 / OUTPUT#6 : 03FC 36C9 INPUT#3 / OUTPUT#7 : 03FC 37C8 INPUT#3 / OUTPUT#8 : 03FC 38C7 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 8: Power Off Mode
Output -5 : VGA-5 VGA+Audio Signal from source device Output -6 : VGA-6 VGA+Audio Signal from source device Output -7 : VGA-7 VGA+Audio Signal from source device Output -8 : VGA-8 VGA+Audio Signal from source device Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 9: Rs-232 Protocol Commands
Note1: Feedback for a command repeats the original command. Example, if x1$ is a command, the feedback is the same and if the command is x2$, the feedback would also be x2$. Note2: If command fails, the feedback should be “Command FAILED”. Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 10: Connection Diagram
CONNECTION DIAGRAM Monitor 8 Monitor 3 Monitor 1 receiver #8r receiver #3 eceiver #1 PC RS232 Control PC 8 PC 6 PC 4 PC 2 PC 7 PC 5 PC 3 PC 1 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 11: Safety Information
It may also cause damage to your AT-PRO2HD88M. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 12: Warranty
Atlona Technologies’ decision, either return of the price paid for the product, repair, or replacement of the product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of the Customer’s receipt. This Limited Warranty is void if failure of the product has resulted from accident, abuse, misapplication, or natural occurrence. -
Page 13: Atlona Product Registration
ATLONA PRODUCT REGISTRATION Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll receive notification of performance issues and firmware updates.
