  • Page 1 MANO860 Intel® Core™ i7/ i5/ i3/ Celeron with QM67Mini-ITX Motherboard User’s Manual...

  • Page 2: Table Of Contents

    MANO860 User’s Manual Contents Product highlights ..................... 8 1.1.1 Product Overview ......................8 1.1.2 Platform Features and Benefits ..................8 1.1.3 Key Architecture Features ..................... 9 Before you Proceed ....................10 Motherboard Overview .................... 10 1.3.1 Placement Direction ..................... 10 1.3.2 Screw Holes .........................
  • Page 3 MANO860 User’s Manual 1.8.7 Audio Mic.-In & Line-Out Connector (FPAUD1) ............32 1.8.8 LVDS Connector (LVDS1) ................... 32 1.8.9 LCD Inverter Connector (JBL1) ................... 33 1.8.10 SPI Connector (JSPI) ....................34 1.8.11 LPC Connector (JLPC1) .................... 34 1.8.12 Serial ATA 3 Connector (SATA1, SATA2) ..............35 1.8.13 Serial ATA II Connector (SATA3 , SATA4 , SATA5) ..........
  • Page 4 MANO860 User’s Manual 2.5.1.1 Intel IGFX Configuration ................... 71 2.5.1.1.1 LCD Control ......................72 2.5.1.2 DMI Configuration ..................... 74 2.5.1.3 NB PCIe Configuration ....................75 2.5.1.4 Memory Configuration ....................76 2.5.2 PCH-IO Configuration ....................77 2.5.2.1 USB Configuration ....................78 2.5.2.2 PCI Express Configuration ..................

  • Page 5: Safety Information

    MANO860 User’s Manual Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 6: About This Guide

    If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the Axiomtek Taiwan website: http://www.axiomtek.com...

  • Page 7: Conventions Used In This Guide

    MANO860 User’s Manual Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task.

  • Page 8: Packing List

    MANO860 User’s Manual Packing List Before you begin installing your single board, please make sure that the following materials have been shipped:  1 x MANO860 Mini-ITX Main board  1 x CD-ROM contains OS drivers  2 x COM cable ...
  • Page 9 MANO860 User’s Manual Display Intel® GMA HD 2000/ 3000 supports DirectX 10.1, OpenGL 3.0 Chipset Shared Memory, up to 1.7GB Display Memory VGA + LVDS, VGA + Display Port, VGA + HDMI, Display Port + HDMI, Dual Display LVDS + HDMI, LVDS + Display Port Onboard, supports max resolution 2048 x 1536 Onboard HDMI 1.3, supports max resolution 1920 x 1080...
  • Page 10 MANO860 User’s Manual Internal I/O Connector 4 USB Connectors support 8 USB Ports, 3 COM RS-232 Connectors with 5V/ 12V Power, 5 SATA Connectors (2 SATA 3.0, 3 SATA II), 1 Front Panel Connector, 1 Front Audio, Internal I/O Connector...

  • Page 11: Block Diagram

    MANO860 User’s Manual Block Diagram BIOS Setup...

  • Page 12: Product Highlights

    MANO860 User’s Manual Chapter 1 - Product Introduction 1.1 Product highlights 1.1.1 Product Overview Supports latest Intel rPGA998 CPU-socket interface processor, the 2nd Generation Intel® Core i3, i5, i7, Celeron mobile processors which are built on 32 nm technologies to provide smart performance and responsiveness on executing tasks, It combines the CPU and GPU to offer fantastic HD media and graphics, especially on 3D gaming experience.

  • Page 13: Key Architecture Features

    MANO860 User’s Manual 1.1.3 Key Architecture Features • Supports Intel LGA 1155 CPU, the 2nd Generation Intel® Core i3, i5, i7 desktop processors. - 32nm monolithic die - Integrated Gfx (Intel® HD Graphics 3000/2000) & memory controller - 4 &2 Cores, up to 6MB LLC...

  • Page 14: Before You Proceed

    MANO860 User’s Manual - High Definition Audio - USB: Gen 2.0, up to 12 ports - SMBus 2.0 - LPC Bus • Supports SPI devices - Hardware Monitor Fan control (Voltage, Temp) Watchdog timer Before you Proceed Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 15: Screw Holes

    MANO860 User’s Manual 1.3.2 Screw Holes Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis. Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis.

  • Page 16: Layout Content List

    MANO860 User’s Manual 1.3.4 Layout Content List Slots & socket Label Function Note Page FCPGA988 FCPGA988 socket DIMMA1 204-pin DDR3 SO-DIMM Slot A1 DIMMB1 204-pin DDR3 SO-DIMM Slot B1 PCIEX16 PCI-e x16 Slot MINI-PCIE MINI PCI-e Slot CFAST Cfast Slot...

  • Page 17: Internal Connector

    MANO860 User’s Manual 1.3.5 Internal Connector Internal Connector Label Function Note Page CPU_FAN1 CPU Fan Connector 3 x 1 wafer, pitch 2.54mm SYS_FAN1 System Fan Connector 3 x 1 wafer, pitch 2.54mm COM3 ~ 5 Serial Port Connector * 3 5 x 2 header, pitch 2.54mm...

  • Page 18: Installing The Cpu

    Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket pins/motherboard components. Axiomtek will shoulder the cost of repair only if the damage is shipment/transit-related.
  • Page 19 MANO860 User’s Manual Before installing the CPU, make sure that the socket box is facing towards you and the load lever is on your left. Separate CPU cooler and its base first by screw drawer 3. Assemble the CPI FAN retention module 4.
  • Page 20 MANO860 User’s Manual CPU Socket triangle Gold triangle BIOS Setup...
  • Page 21 MANO860 User’s Manual 5. turn the CPU lock clockwise to lock CPU The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU!

  • Page 22: Installing The Cpu Heatsink And Fan

    MANO860 User’s Manual 1.4.2 Installing the CPU Heatsink and Fan Place the heatsink base on the relative bottom of motherboard Place the heatsink assembly on the top of the CPU, making sure that the four fasteners match the holes on the motherboard.

  • Page 23: System Memory

    MANO860 User’s Manual System Memory 1.5.1 Overview The motherboard comes with Two 204-pin Double Data Rate 3 (DDR3) Small Outline Dual Inline Memory Modules (SO-DIMM) sockets. A DDR3 module has the same physical dimensions as a DDR SO-DIMM but has a 204-pin footprint compared to the 200-pin DDR2 DIMM.

  • Page 24: Memory Configurations

    MANO860 User’s Manual 1.5.2 Memory Configurations You may install 1 GB, 2 GB , and 4 GB unbuffered ECC or non-ECC DDR3 SO-DIMMs into the SO-DIMM sockets using the memory configurations in this section.  IF you installed 4GB memory modules, the system may detect less than 3GB of total memory because of address space allocation for other critical functions.
  • Page 25 MANO860 User’s Manual Align a SO-DIMM on the socket such that the notch on the SO-DIMM matches the break on the socket. DDR3 SO-DIMM notch Unlocked retaining clip Firmly insert the SO-DIMM into the socket until the retaining clips snap back in place and the SO-DIMM is properly seated.

  • Page 26: Removing A So-Dimm

    MANO860 User’s Manual  A DDR3 SO-DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a SO-DIMM into a socket to avoid damaging the SO-DIMM.  The DDR3 SO-DIMM sockets do not support DDR SO-DIMMs. DO NOT install DDR2 SO-DIMMs to the DDR3 SO-DIMM socket.

  • Page 27: Expansion Card

    MANO860 User’s Manual Expansion Card In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Make sure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

  • Page 28: Mini Pci Express

    MANO860 User’s Manual 1.6.4 MINI PCI Express This motherboard supports one MINI PCI Express. The following figure shows a Decode card installed on the MINI PCI Express slot. 1.6.5 CFast Card This motherboard supports one CFast Card connector and its location is on button side of MB. The following figure shows a CFast Card installed on the CFast Card connector..

  • Page 29: Jumpers

    MANO860 User’s Manual Jumpers 1.7.1 Clear CMOS (CMOS1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which includes system setup information such as system passwords.

  • Page 30: Com3, Com4, Com5 Ri/+5V/+12V Select (Jcompwr3 Jcompwr4 Jcompwr5)

    MANO860 User’s Manual 1.7.2 COM3, COM4, COM5 RI/+5V/+12V Select (JCOMPWR3 JCOMPWR4 JCOMPWR5) This jumper allows you to select the power mode of COM PORTATX Mode or AT mode +12V 1.7.3 LVDS Back Light controller form SIO (JBLK1) ENABLED DISABLED BIOS Setup...

  • Page 31: At/Atx Power Mode Select (Pson1)

    MANO860 User’s Manual 1.7.4 AT/ATX Power Mode Select (PSON1) This jumper allows you to select ATX Mode or AT mode . ATX MODE (Default) AT MODE 1.8 Connectors 1.8.1 Rear panel connectors PS/2 mouse port (green). This port is for a PS/2 mouse.
  • Page 32 MANO860 User’s Manual LAN port LED indications SPEED LED ACT / LINK LED Status Description Status Description 10Mbps connection No link Orange 100Mbps connection Green Link Green 1Gbps connection Blinking Data activity 8. USB 2.0 ports 1 ~ 4. These four 4-pin Universal Serial Bus (USB) ports are available for connecting USB 2.0 devices.

  • Page 33: Cpu And System Fan Connectors (Cpu_Fan1, Sys_Fan1)

    MANO860 User’s Manual 1.8.2 CPU and System fan connectors (CPU_FAN1, SYS_FAN1) The fan connectors support cooling fans of 280mA (3.36 W max.) at 4800rpm or a total of 1A~2.22A (26.64W motherboard, making sure that the max.) at +12V. Connect the fan cables to the fan connectors on the black wire of each cable matches the ground pin of the connector.

  • Page 34: Atx Power Connectors (Eatxpwr1, Atx12V1)

    MANO860 User’s Manual  ATX Power Button/Soft-off Button (Pin 6-8 PWRBT) This 2-pin connector is for the system power button. Pressing the power button turns the system on or Pressing the power switch puts the system in sleep or soft-off mode depending on the BIOS settings.

  • Page 35: Serial Port Connectors (Com3, Com4, Com5)

    MANO860 User’s Manual 1.8.5 Serial Port connectors (COM3, COM4, COM5) This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis.

  • Page 36: Audio Mic.-In & Line-Out Connector (Fpaud1)

    MANO860 User’s Manual 1.8.7 Audio Mic.-In & Line-Out Connector (FPAUD1) This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC ‘97 (optional) audio standard. Connect one end of the front panel audio I/O module cable to this connector.

  • Page 37: Lcd Inverter Connector (Jbl1)

    MANO860 User’s Manual 1.8.9 LCD Inverter Connector (JBL1) The connector is for the control of internal LVDS brightness.  Signal Description Signal Signal Description For inverter with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal.

  • Page 38: Spi Connector (Jspi)

    MANO860 User’s Manual 1.8.10 SPI Connector (JSPI) Is a point-to-point interface standard, which allows network equipment designers to develop an array of next-generation multi-service switches and routers to support multi-service traffic with aggregate bandwidths up to OC-192 (10 Gb/s) and beyond, enabling them to dramatically increase system performance.

  • Page 39: Serial Ata 3 Connector (Sata1, Sata2)

    MANO860 User’s Manual 1.8.12 Serial ATA 3 Connector (SATA1, SATA2) These connectors support SATA 3.0 and are for the Serial ATA signal cables for Serial ATA hard disk drives. SATA1、SATA2 1.8.13 Serial ATA II Connector (SATA3 , SATA4 , SATA5) These connectors support SATA 2.0 and are for the Serial ATA signal cables for Serial ATA hard disk drives.

  • Page 40: Case Open Connectors (Jcase1)

    MANO860 User’s Manual 1.8.14 Case open connectors (JCASE1) JCASE1 1.8.15 USB connectors (USB56, USB78, USB910, USB1112,) These connectors are for USB 2.0 ports. Connect the optional USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed.

  • Page 41: Bios Setup Program

    MANO860 User’s Manual Chapter 2 - BIOS Setup 2.1 BIOS Setup Program This motherboard supports a programmable firmware chip that you can update using the provided utility. Use the BIOS Setup program when you are installing a motherboard, reconfiguring your system, or prompted to “Run Setup.”...

  • Page 42: Legend Box

    MANO860 User’s Manual 2.1.1 Legend Box The keys in the legend bar allow you to navigate through the various setup menus Key(s) Function Description ← Select Screen ↑↓ Select Item Change Option / Field/ Value Enter Go to Sub Screen...

  • Page 43: Bios Menu Screen

    MANO860 User’s Manual 2.2 BIOS Menu Screen When you enter the BIOS, the following screen appears. The BIOS menu screen displays the items that allow you to make changes to the system configuration. To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu.

  • Page 44: Main Setup

    MANO860 User’s Manual 2.3 Main Setup This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. Use this menu for basic system configurations, such as time, date etc.  BIOS Information Display the auto-detected BIOS information.

  • Page 45: Advanced Bios Setup

    MANO860 User’s Manual 2.4 Advanced BIOS Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Chipset configuration, to go to the sub menu for that item.

  • Page 46: Pci Subsystem Setting

    MANO860 User’s Manual 2.4.1 PCI Subsystem Setting The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting IRQ and DMA channel resources for either PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA devices.
  • Page 47 MANO860 User’s Manual  PERR# Generation [Disable] Enables or disables PCI devices to Generate PERR#. Configuration options: [Disabled] [Enabled]  SPERR# Generation [Disable] Enables or disables PCI devices to Generate SPERR#. Configuration options: [Disabled] [Enabled]  PCI Express Device Settings ...

  • Page 48: Acpi Settings

    MANO860 User’s Manual 2.4.2 ACPI Settings  ACPI Sleep State [S3 (suspend to RAM)] Select the highest ACPI sleep state the system will enter the SUSPEND button is press. Configuration options: [Suspend Disable][S1 (CPU Stop Clock)] [S3 (suspend to RAM )] ...

  • Page 49: Trusted Computing

    MANO860 User’s Manual 2.4.3 Trusted computing Trusted computing (TPM) settings. TPM configuration  TPM SUPPORT [Disabled] Enable or disable TPM support. Configuration options: [Disabled] [Enabled]  Current TPM Status Information Displays the TPM status information [No TPM Hardware] BIOS Setup...

  • Page 50: Cpu Configuration

    MANO860 User’s Manual 2.4.4 CPU configuration  CPU configuration Displays the CPU information  Hyper-threading [Enabled] Enable or disable Hyper-threading support. Configuration options: [Disabled] [Enabled]  Active Processor Cores [All] Select the numbers of cores in each processor package. Configuration options: [All] [1] [2] [3] [4] [5] [6] [7] It depends on each CPU type.
  • Page 51 MANO860 User’s Manual  Execute Disable Bit [Enable] XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS ( Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2 RedHat Enterprise 3 Update 3.) Configuration options: [Disabled] [Enabled] ...

  • Page 52: Sata Configuration

    MANO860 User’s Manual 2.4.5 SATA Configuration  SATA Mode [IDE Mode] Support IDE, AHCI or RAID mode Configuration options: [Disable][IDE Mode][AHCI Mode][RAID Mode]  Serial-ATA Controller 0 [Compatible] Enabled/Disabled Serial-ATA Controller 0 Configuration options: [Disable] [Enhanced] [Compatible]  Serial-ATA Controller 1 [Enhanced]...

  • Page 53: Intel Txt(Lt) Configuration

    MANO860 User’s Manual 2.4.6 Intel TXT(LT) Configuration Display Intel Trusted Execution Technology configuration. BIOS Setup...

  • Page 54: Pch-Fw Configuration

    MANO860 User’s Manual 2.4.7 PCH-FW Configuration Configuration Management Engine Technology Parameter  Display ME Firmware Information BIOS Setup...

  • Page 55: Firmware Update Configuration

    MANO860 User’s Manual 2.4.7.1 Firmware Update Configuration BIOS Setup...
  • Page 56 MANO860 User’s Manual  Me FW Image Re-Flash[Disable] Enabled/Disabled Me FW Image Re-Flash function Configuration options: [Disable] [Enhanced] BIOS Setup...

  • Page 57: Amt Configuration

    MANO860 User’s Manual 2.4.8 AMT Configuration Configuration AMT Parameters  Intel AMT [Enable] Enabled/Disabled AMT Configuration options: [Disabled] [Enabled]  Intel AMT Setup Prompt [Enable] Enabled/Disabled Intel AMT setup prompt to wait for hot-key to enter setup. Configuration options: [Disabled] [Enabled] ...
  • Page 58 MANO860 User’s Manual  Hide Un-configure ME Configuration[Disable] Hide Un-configure ME without password Configuration prompt. Configuration options: [Disabled] [Enabled]  MEBx Debug Message Output [Disable] Enabled/Disabled MEBx debug massage output. Configuration options: [Disabled] [Enabled]  Un-configure ME [Disable] Un-configure ME without password.

  • Page 59: Usb Configuration

    MANO860 User’s Manual 2.4.9 USB Configuration USB Configuration Parameters  USB Device Display how many devices are connected.  Legacy USB Support [Enabled] Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

  • Page 60: Super Io Configuration

    MANO860 User’s Manual USB hardware delays and time-outs:  USB transfer time-out [20 sec] The time-out value for Control, Bulk, and Interrupt transfers. Configuration options: [1 sec] [5 sec] [10 sec] [20 sec]  Device reset time-out [20 sec] USB mass storage device Start Unit command time-out.

  • Page 61: Serial Port 0 Configuration

    MANO860 User’s Manual 2.4.10.1 Serial Port 0 configuration Set Parameters of Serial Port 0 (COMA) Serial Port 0 Configuration  Serial Port [Enable] Enable or Disable Serial Port. Configuration options: [Disabled] [Enabled]  Device Setting [IO=3F8h; IRQ=4]  Change Setting[Auto] Select an optimal setting for Super IO device.

  • Page 62: Serial Port 1 Configuration

    MANO860 User’s Manual 2.4.10.2 Serial Port 1 configuration Set Parameters of Serial Port 3 (COM3) Serial Port 1 Configuration  Serial Port [Enable] Enable or Disable Serial Port. Configuration options: [Disabled] [Enabled]  Device Setting [IO=C80h; IRQ=5]  Change Setting[Auto] Select an optimal setting for Super IO device.

  • Page 63: Serial Port 2 Configuration

    MANO860 User’s Manual 2.4.10.3 Serial Port 2 configuration Set Parameters of Serial Port 4 (COM4) Serial Port 2 Configuration  Serial Port [Enable] Enable or Disable Serial Port. Configuration options: [Disabled] [Enabled]  Device Setting [IO=C88h; IRQ=5]  Change Setting[Auto] Select an optimal setting for Super IO device.
  • Page 64 MANO860 User’s Manual 2.4.10.4 Serial Port 3 configuration Set Parameters of Serial Port 5 (COM5) Serial Port 3 Configuration  Serial Port [Enable] Enable or Disable Serial Port. Configuration options: [Disabled] [Enabled]  Device Setting [IO=C90h; IRQ=5]  Change Setting[Auto] Select an optimal setting for Super IO device.

  • Page 65: Smart Fan Mode Configuration

    MANO860 User’s Manual 2.4.10.5 Smart Fan Mode Configuration Smart Fan Mode configuration  System Fan Mode [Manual Mode] Select system Fan mode Configuration options: [Manual Mode] [Thermal Cruise Mode][SNART FAN IV Mode]  CPU Fan Mode [Manual Mode] Select CPU Fan mode Configuration options: [Manual Mode] [Thermal Cruise Mode][SNART FAN IV Mode] ...

  • Page 66: Digital I/O Configuration

    MANO860 User’s Manual  Resume on PS2 MS[Disabled] Enable or Disable Resume on PS2 MS Function Configuration options: [Disabled] [Enabled]  Resume on Ring [Disabled] Enable or Disable Resume on Ring Function Configuration options: [Disabled] [Enabled]  Watch Dog Timer [Disabled]...
  • Page 67 MANO860 User’s Manual  Digital I/O Pin 2 [Input] Configure Digital I/O Pin Configuration options: [Input][Output High][Output Low]  Digital I/O Pin 3 [Input] Configure Digital I/O Pin Configuration options: [Input][Output High][Output Low]  Digital I/O Pin 4 [Input] Configure Digital I/O Pin Configuration options: [Input][Output High][Output Low] ...

  • Page 68: Hardware Monitor

    MANO860 User’s Manual 2.4.11 Hardware Monitor  PC Health Stutus Display system health status  CPU Warning Temperature [Disable] Enabled or Disabled CPU warning temperature Function Configuration options: [Disable] [50 C/122 F] [55 C/131] [60 C/140 F] [65 C/149 F] [70 C/158 F] [75 C/167 F] ...

  • Page 69: Serial Port Console Redirection

    MANO860 User’s Manual 2.4.12 Serial Port Console Redirection Display COM console information.  Console Redirection [Enable] Console Redirection Enable or Disable Configuration options: [Disabled] [Enabled]  Out-of-Band Mgmt port [COM0 (Disabled)] Microsoft Windows Emergency management Services (EMS) allows for remote management of a Windows Server OS though a serial port.

  • Page 70: Intel Icc

    MANO860 User’s Manual 2.4.13 Intel ICC Integrated Clock Control Option.  Use Watchdog Timer for ICC[Disable] Enable Watchdog Timer operation for ICC. Configuration options: [Disabled] [Enabled]  Turn off unused PCI/PCIe clocks [Enable] Enable or Disable clocks for empty PCI/PCIe slots to save power.

  • Page 71: Sandybridge Dts Configuration

    MANO860 User’s Manual 2.4.14 Sandybridge DTS Configuration  CPU DTS[Enable] Enable or Disable CPU DTS. Configuration options: [Disabled] [Enabled] BIOS Setup...

  • Page 72: Sandybridge Ppm Configuration

    MANO860 User’s Manual 2.4.15 Sandybridge PPM Configuration  EIST [Enable] Enable or Disable Intel Speedstep. Configuration options: [Disabled] [Enabled]  CPU C3 Report[Enable] Enable or Disable CPU C3 report to SO. Configuration options: [Disabled] [Enabled]  CPU C6 Report[Enable] Enable or Disable CPU C6 report to SO.

  • Page 73: Chipset

    MANO860 User’s Manual 2.5 Chipset BIOS Setup...

  • Page 74: System Agent (Sa) Configuration

    MANO860 User’s Manual 2.5.1 System Agent (SA) Configuration  System Agent RC version Display System Agent RC information.  VT-d [Disable] Set VT-d Enable or Disable Configuration options: [Disabled] [Enabled]  Primary Display [Auto] Select primary Display Configuration options: [Auto] [IGFX] [PEG] [PCI] ...

  • Page 75: Intel Igfx Configuration

    MANO860 User’s Manual 2.5.1.1 Intel IGFX Configuration  Intel IGFX Configuration Display IGFX VBIOS version & IGFX Frequency  Graphic Turbo IMNO Current[31] Graphic Turbo IMNO Current values supported(14-31)  Internal Graphic[Auto] Keep IGD enable based on the setup option.

  • Page 76: Lcd Control

    MANO860 User’s Manual  DVMT Total GFX Mem[MAX] Select DVMT5.0 total graphic memory size. Configuration options: [128MB][256MB] [MAX]  Gfx Low Power Mode[Disable] This option is applicable for SFF only. Configuration options: [Disabled] [Enabled] 2.5.1.1.1 LCD Control LCD Control ...
  • Page 77 MANO860 User’s Manual  BIA[Auto] Auto: GMCH use VBT Default Level n: Enabled with selected Aggressiveness level. Configuration options: [Auto] [Disabled] [Level 1] [Level 2] [Level 3] [Level 4] [Level 5]  Spread Spectrum clock Chip[Off] Hardware: Spectrum is controlled by Chip.

  • Page 78: Dmi Configuration

    MANO860 User’s Manual 2.5.1.2 DMI Configuration  DMI Vc1 Contorl[Enable] Enable or disable DMI Vc1 Configuration options: [Disabled] [Enabled]  DMI Vcp Contorl[Enable] Enable or disable DMI Vcp Configuration options: [Disabled] [Enabled]  DMI Vcm Contorl[Enable] Enable or disable DMI Vcm Configuration options: [Disabled] [Enabled] ...

  • Page 79: Nb Pcie Configuration

    MANO860 User’s Manual 2.5.1.3 NB PCIe Configuration  PEG0 – Gen X Configure PEG0 B0 :D1 :F0 Gen1-Gen2 Configuration options: [Auto] [Gen1] [Gen2]  PEG1 – Gen X Configure PEG1 B0 :D1 :F1 Gen1-Gen2 Configuration options: [Auto] [Gen1] [Gen2] ...

  • Page 80: Memory Configuration

    MANO860 User’s Manual  ASPM L0s[Both Boot and Endpoint Ports] Enable PCIe ASPM L0s. Configuration options: [Boot Port only] [Endpoint Port only] [Both Boot and Endpoint Ports]  De-emphasis Control[-3.5 dB] Configure the De-emphasis control on PEG. Configuration options: [-6 dB] [-3.5 dB] 2.5.1.4 Memory Configuration...

  • Page 81: Pch-Io Configuration

    MANO860 User’s Manual  NMode Support[Auto] NMode support Option. Configuration options: [Auto] [1N Mode] [2N Mode]  Memory Scrambler [Disable] Enable or Disable Memory Scrambler support. Configuration options: [Disabled] [Enabled]  RMT Crosser Support[Disable] Enable or Disable RMT Crosser Support.
  • Page 82 MANO860 User’s Manual  Intel PCH Information  LAN1 Controller [Enable] Enable/Disable LAN1 Controller Configuration options: [Disabled] [Enabled]  LAN1 Option-ROM [Disable] Enable/Disable LAN1 boot option for legacy network devices. Configuration options: [Disabled] [Enabled]  Wake on LAN1 from S5 [Disable] Configuration options: [Disabled] [Enabled] ...

  • Page 83: Usb Configuration

    MANO860 User’s Manual 2.5.2.1 USB Configuration  EHCI1 [Enabled] Enable/Disable USB 2.0(EHCI) support Configuration options: [Disabled] [Enabled]  EHCI2 [Enabled] Enable/Disable USB 2.0(EHCI) support Configuration options: [Disabled] [Enabled] BIOS Setup...

  • Page 84: Pci Express Configuration

    MANO860 User’s Manual 2.5.2.2 PCI Express Configuration  PCI Express Clock Gating[Enable] Enable or Disable PCI Express clock gating for each root port. Configuration options: [Disabled] [Enabled]  DMI Link ASPM Contorl[L0sL1] Enable or disable the control of active state power management on SA side of the DMI link.

  • Page 85: Pci Express Root Port 1

    MANO860 User’s Manual 2.5.2.2.1 PCI Express Root Port 1 PCI Express Root Port 1 setting. Configuration options: [Disabled] [Enabled][Auto]  PCI Express Root Port 1 [Enable]. Enable or Disable to cintrol PCI Express Root Port. Configuration options: [Disabled] [Enabled][Auto] ...

  • Page 86: Boot

    MANO860 User’s Manual 2.6 Boot Boot Configuration  Setup Prompt Timeout [1] Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.  Bootup NumLock State [On] Select the keyboard NumLock state Configuration options: [On] [Off] ...

  • Page 87: Security

    MANO860 User’s Manual  Option ROM Messages [Force BIOS] Set display mode for option ROM. Configuration options: [Force BIOS] [Keep Current]  Interrupt 19 Capture [Disable] Enabled : Allow option ROMs to trap Int19. Configuration options: [Disabled][Enabled]  Boot option priorities [Built-in EFI Shell] Select the system boot order.

  • Page 88: Save & Exit

    MANO860 User’s Manual 2.8 Save & Exit  Save changes and Exit Exit system setup after saving the changes.  Discard changes and Exit Exit system setup without saving the changes.  Save changes and Reset Reset the system after saving the changes.
