CORDLESS
DRILL
DRIVER
12V
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
12V
Chuck Size:
10mm Keyless
No Load Speed:
0-700/min
Torque Setting:
18
Max. Torque:
12Nm
Drilling Capacity:
22mm Wood
8mm Steel
Battery:
1.5Ah Li-ion
Charge time:
3 - 5 hours
Weight with Battery:
0.95 kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Drill Driver
12V Battery
Driver Bits x 5
Bit Adaptor
Charging Cradle
Charging Adaptor
LCD-3100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito LCD-3100
Summary of Contents for Ozito LCD-3100
- Page 1 Chuck Size: 10mm Keyless Bit Adaptor No Load Speed: 0-700/min Torque Setting: Max. Torque: 12Nm Drilling Capacity: 22mm Wood 8mm Steel Battery: 1.5Ah Li-ion Charging Cradle Charge time: 3 - 5 hours Weight with Battery: 0.95 kg ozito.com.au Charging Adaptor LCD-3100...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS DRILL DRIVER 1. BATTERY 1 Keyless chuck 5 Forward/ reverse lever This charger is recommended for use with a residual current 2 Torque adjustment collar 6 Battery release button device with a rated residual current of 30mA or less. 3 LED worklight 7 12V Battery Charging...
- Page 3 OPERATION 2. KEYLESS CHUCK 3. CONTROLS Variable Speed Trigger Installing Drill Bit 1. To start drilling squeeze 1. Hold the back sleeve of 2. With the other hand, turn the variable speed the chuck with one hand. the first chuck sleeve anti- trigger. clockwise. 2.
- Page 4 If the bit jams in the work piece or if the drill stalls, stop the tool immediately. Remove the bit from the work piece and determine the Note: Do not force the drill or apply side pressure to elongate the reason for jamming. hole. Let the drill do the work. LCD-3100...
- Page 5 Blow out the ventilation slots with compressed air periodically . Ensure the battery is properly charged. It will take 4-5 charging cycles Note: Ozito Industries will not be responsible for any damage or before the battery reaches optimum charge and run time. On the initial injuries caused by repair of the drill by an unauthorised person or by charge, the battery requires 5 hours of charging.
- Page 6 Tool: 12V Li-ion Dril Driver SPARE PARTS Model No. LCD-3100 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. 12V Lithium Ion Batter...
- Page 7 Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0813...
