4 OPERATION GUIDE

Before using the NAVI-XS POI, make sure to prepare the following items:
♦ GPS software is properly installed on your Bluetooth™-enabled
device (PC, laptop, Pocked PC, or other handheld devices).
♦ The Bluetooth™ GPS Receiver is fully powered (i.e. internal batteries
are full charged) and operational.
♦ Check that the Bluetooth™ GPS Receiver is ON.
This section will outline the necessary procedures for the Bluetooth™ GPS receiver to
run smoothly with the GPS Mapping software.

4.1 Installation instructions

In the delivery package the NIMH 800 mA/h (2 x 1.2 V) batteries for NAVI-XS POI are
separately packed, just take them out from the package, open the cover cap on
the underside of the NAVI-XS POI and insert both batteries in it. Note, insert the
batteries with the correct polarity. Check the polarity marks on the battery (positive
[+] and negative [-]) before mounting the batteries in the device. Insert the batteries
as shown on the edges of the device's housing. Finally, close the cover cap. In the
box there is also a cradle and a small adhesive pad, with a peel off sticky base. The
user simply has to remove the sticker cover, and position it on the top of the
dashboard (or in any place you want). Then stick the cradle to the adhesive pad.
Insert the power jack into the cigar lighter (not included), and plug the other end of
the lead into the NAVI-XS POI unit, then put the NAVI-XS POI into the cradle, in such a
way it is facing toward the sky. Once the NAVI-XS POI unit is connected to the
external power source it starts charging process (refer to chapter
details). The NAVI-XS POI unit has three LEDs on the top of the unit, providing
additional information to the GPS, Bluetooth and Batteries state. During charging the
middle LED flashes green, see also table 4. Charging will be terminated after the
batteries reach full capacity (800 mA/h), which approximately takes 2-3 hours. After
batteries are fully charged, turn on the NAVI-XS POI unit by pressing the ON-button for
longer than two seconds until a short beep is heard. Please, refer to the chapter
to perform a Bluetooth™ connection between the Falcom NAVI-XS POI unit
4.1.1
and your mobile phone/PDA/PC or laptop.
Note: For best results, the NAVI-XS POI should also perform a GPS fix now. The
GPS indicator will light steadily when a valid GPS fix is obtained. If there is
trouble during acquire a GPS fix, replace the location of NAVI-XS POI or
restart it again.
