- Page 1 CP-1262HE HDMI to PC/Component Converter with Audio Box Operation Manual CP-1262HE...
-
Page 2: Copyright Notice
Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document. -
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents Introduction ……………………..……………………...…..….……. Features …………………………………………..……..…...…… Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Connection and Installation ….…………………..…..…..…..HDMI Connector Pin Assignment ....…..…..…..…... Specifications ………………………………...……..………..…. Acronyms ….................. -
Page 5: Introduction
1. Introduction This converter box converts digital HDMI to Analog PC or SD/HD output. It enables to connect the HDMI sources to the analog PC monitor, Projector or TV. Its high bandwidth capability supports a wide range of PC and HDTV resolutions. -
Page 6: Operation Controls And Functions
3. Operation Controls and Functions 3.1 Front Panel OUTPUT HDMI INPUT DC 5V YPbPr ① ② ③ ① YPbPr/RGB switch: Set the switch to RGB when your HDMI source equipment is PC graphic card or other digital RGB source signal. Use HD- 15 to HD-15 VGA cable to connect between the unit's RGB out and the RGB input of your PC monitor, or projector. -
Page 7: Connection And Installation
4. Connection and Installation Connection 1(RGB out) VGA cable HDMI out 3.5mm to 2 RCA DVD or, Set-Top-Box audio cable LCD Monitor/TV Projector HDMI cable DVI out DVI to HDMI adaptor Connection 2 (YPbPr out) YPbPr cable D-Sub to 3 RCA cable HDMI cable DVD or, Set-Top-Box Audio... -
Page 8: Hdmi Connector Pin Assignment
5. HDMI Connector Pin Assignment Pin# Function Assignment Pin# Function Assignment TMDS Data2+ TMDS Data2 Shield TMDS Data2- TMDS Data1+ TMDS Data1 Shield TMDS Data1- TMDS Data0+ TMDS Data0 Shield TMDS Data0- TMDS Clock+ TMDS Clock Shield TMDS Clock- Reserved (N.C. on device) DDC/CEC Ground +5V Power Hot Plug Detect... -
Page 9: Specifications
6. Specifications Operation Frequency Up to 225MHz Input Port 1 x HDMI Output Ports 1 x HD-15 D-Sub (RGBHV or YPbPr) 1 x Analog L/R 3.5mm phone jack Output Signal RGB: 0.7Vp-p 75ohm H/V: 3 to 5 Vp-p Or Y: 1 Vp-p 75ohm PB/Pr: 0.7 Vp-p 75ohm Input/Output Resolution PC: 640x480= VGA59 , VGA60, VGA72, VGA75,... -
Page 10: Acronyms
Acronyms Acronym Complete Term... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080818 MPM-CP1262HE...
