SPECIFICATIONS
2.1 MODEL NUMBERS:
FRUVD – Fits FrontRunner with 52", 60", or 72" deck
FRCK524 – Completing kit for FrontRunner with 52" deck
FRCK604 – Completing kit for FrontRunner with 60" deck
FRCK724 – Completing kit for FrontRunner with 72" deck
Note: Dual tail wheels are REQUIRED for maximum stability, clearance, and capacity.
FRDTWK – Complete kit to install dual tail wheels.
FRDTWA – Partial kit to install dual tail wheels, re-uses some components from single tailwheel.
2.2 DIMENSIONS
2.2.1 Overall unit length w/ Ultra Vac
52" Deck
118.21" (300.3 cm) 118.32" (300.5 cm) 121.2" (307.8 cm)
2.2.2 Overall unit width w/ Ultra Vac
52" Deck
60" Deck
72" Deck
2.2.3 Overall weight
52" Deck
60" Deck
72" Deck
2.3 BAGGING SYSTEM
2.3.1 Collection bin: Commercial grade rotationally molded plastic.
Capacity: 12 bushels
2.3.2 Dump Mechanism: Manual dump from seat.
2.3.3 Blower tube: flexible, abrasion resistant EPDM rubber with polypropylene helix.
2.3.4 Impeller: 5-bladed, 0.25" thick abrasion resistant steel, with vertical axis.
2.3.5 Impeller bearings: 1" (2.54 cm) sealed "non-greaseable bearings"
3. OPERATION:
3.1 PRE-START
3.1.1 Read the operator's manual for your mower and familiarize yourself with all
controls before operating the machine. Make sure that you understand the
controls, their locations, their functions, and their safety requirements.
3.1.2 Ensure the blower, belt cover, flexible tube, hopper, and door are in good
condition, properly attached, and latched.
Note: When mowing in areas with sandy soil, use low lift blades on the cutting deck
and higher cutting heights to minimize wear on the blower components.
3.2 MOWING
3.2.1 The Ultra Vac blower operates when deck drive is engaged. Be sure that all
persons are clear of the mower deck and blower before engaging the cutting
60" Deck
66.85" (169.8 cm)
74.44" (189.1 cm)
87.10" (221.2 cm)
264 lbs. (119 kg)
265 lbs. (120 kg)
265 lbs. (120 kg)
6
72" Deck
