Specifications

Systems

Bagging System
• Collection bins:
– Commercial grade, cloth mesh bags with
reinforced bottoms.
– 2-Bagger Capacity: 8.0 bushels
– 3-Bagger Capacity: 13.4 Bushels
• Dump Mechanism: Manual lift off
• Blower Tube: Fixed, abrasion resistant molded
polyethylene.
• Impeller: 5–bladed, 1/4 inch (6.4 mm) thick
abrasion resistant steel, with vertical axis.
• Impeller bearings: 1 inch (2.5 cm) sealed
non-greaseable bearings.

Dimensions

Overall Width:
2-Bagger
Lazer Z w/48 inch Deck
Lazer Z w/52 inch Deck
3-Bagger
Lazer Z w/60 inch Deck
Lazer Z w/72 inch Deck
w/UltraVac
62.50 inches (158.8 cm)
67.75 inches (172.1 cm)
w/UltraVac
75.00 inches (190.5 cm)
87.25 inches (221.6 cm)
Overall Length:
2-Bagger
Lazer Z w/48 inch Deck
Lazer Z w/52 inch Deck
3-Bagger
Lazer Z w/60 inch Deck
Lazer Z w/72 inch Deck
Curb Weight:
2-Bagger
For units w/48 inch Deck
(3 toe board weights)
For units w/52 inch Deck
(2 toe board weights)
3-Bagger
For units w/60 inch Deck
(2 toe board weights)
For units w/72 inch Deck
(1 toe board weights)

Torque Requirements

Bolt Location
Impeller Spindle Bottom
Nut
Impeller Spindle Top Nut
9
Specifications
w/UltraVac
102.25 inches (259.7 cm)
102.25 inches (259.7 cm)
w/UltraVac
107.00 inches (271.8 cm)
110.00 inches (279.4 cm)
UltraVac Weight
309 lb (140 kg)
266 lb (120 kg)
UltraVac Weight
449 lb (204 kg)
406 lb (184 kg)
Torque
55-60 ft-lb (75-81 N-m)
75-80 ft-lb (102-108 N-m)
