Technical Specifications

INPUTS:
OUTPUTS:
PORT:
BANDWIDTH:
STANDARDS:
STEP-IN
COMMANDER
DISTANCE:
OUTPUT
DISTANCE:
POWER
CONSUMPTION:
OPERATING
TEMPERATURE:
STORAGE
TEMPERATURE:
HUMIDITY:
DIMENSIONS:
WEIGHT:
ACCESSORIES:
OPTIONS:
REMOTE STEP-IN
COMMANDERS
VP-81SIDN - Technical Specifications
Video:
8 TP on RJ-45 connectors
1 DVI-D on a Molex 24-pin (F)
connector
1 HDMI connector
Video:
1 TP on an RJ-45 connector
1 HDMI connector
USB Power: 5V DC USB power
1.65Gbps per channel
HDMI with Deep Color, x.v.Color™ and 3D
50m (164ft) up to 1080p @60Hz
50m (164ft) up to 1080p @60Hz
100-240V AC 50/60Hz 70VA
0° to +55°C (32° to 131°F)
-45° to +72°C (-49° to 162°F)
10% to 90%, RHL non-condensing
43.7cm x 18.1cm x 4.4cm (17.2" x 7.1" x 1.7") W, D, H rack-mountable
2.0kg (4.4lbs) approx.
Power cord, Windows
Remote Control transmitter
External remote IR receiver cable (P/N: C-A35M/IRR-50); 15m extension
cable (P/N: C-A35M/A35F-50)
SID-VGA, SID-DP, SID-DVI, SID-H, SID-X1
Audio:
2 Unbalanced stereo audio (1 for DVI and
1 for HDMI) on 3.5mm mini jacks
Audio:
1 balanced stereo audio on a 5-pin
detachable terminal block
1 unbalanced stereo audio on 2 RCA
connectors
1 digital audio on an RCA connector
®
-based Kramer control software, RC-IR3 Infrared
