Kramer VP-81SIDN User Manual page 12

# Feature
12 DVI
LOCAL AUDIO
INPUTS
13 HDMI
14 HDMI OUT Connector
15 +L–G+R–
16 R
AUDIO
OUTPUTS
17 L
18 S/PDIF
19 PROG TERM DIP-Switch
20 RS-485 3-way Terminal Block
21 RESET Button
22 REMOTE IR 3.5mm Mini Jack
Function
Connect to the local DVI audio source
Connect to the local HDMI audio source
Connect to the local HDMI acceptor
Connect to the balanced audio acceptor (see
Connect to the unbalanced audio acceptor right channel
Connect to the unbalanced audio acceptor left channel
Connect to the digital audio acceptor
DIP-Switch 1: Sets the RS-485 bus termination (see
Up = Off, Down = On (Default = On)
DIP-Switch 2: For the use of Kramer service personnel only
Connect to RS-485 port on a remote controller or another VP-81SIDN.
Connect: G to Ground, A to A, and B to B (see
Press while power-cycling the device to reset parameters to factory default values
Connect to an external IR receiver unit for controlling the device via an IR remote
controller (see Section 3.3)
Section 6.1)
Section 8.3).
Section 6.4)
