USER MANUAL

MODEL:
VP-732
Presentation Switcher/Dual Scaler
P/N: 2900-300327 Rev 1
www.kramerAV.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-732 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kramer VP-732

Summary of Contents for Kramer VP-732

  • Page 1: User Manual

    USER MANUAL MODEL: VP-732 Presentation Switcher/Dual Scaler P/N: 2900-300327 Rev 1 www.kramerAV.com...

  • Page 4: Table Of Contents

    Switching the Inputs Preview/Program Operation Mode The PIP Operation Mode Locking and Unlocking the Front Panel The Infrared Remote Control Transmitter Configuring the VP-732 via the OSD MENU Screens The Input Screen The Picture Screen The Output Screen The PIP Screen...
  • Page 5 Figures Figure 1: VP-732 Presentation Switcher/Dual Scaler Front Panel Figure 2: VP-732 Presentation Switcher/Dual Scaler Rear Panel Figure 3: Connecting to the VP-732 Rear Panel Figure 4: UNIV 15-pin HD Connector Pinout Figure 5: Local Area Connection Properties Window Figure 6: Internet Protocol Version 4 Properties Window...
  • Page 6 Figure 53: The Security Page Figure 54: The About Page VP-732 – Contents...

  • Page 7: Introduction

    Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we have redesigned and upgraded...

  • Page 8: Getting Started

    Avoid interference from neighbouring electrical appliances that may adversely influence signal quality  Position your Kramer VP-732 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building.

  • Page 9: Recycling Kramer Products

    Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

  • Page 10: Overview

    Overview The Kramer VP-732 is a 10-input Presentation Matrix Switcher / Dual Scaler for a wide variety of presentation and multimedia applications. The VP-732 has four HDMI, two DisplayPort and four user definable (universal) analog video inputs (each can be set as computer graphics, composite video, s-Video (Y/C) or component video).
  • Page 11 TO XGA/720P button (to hardware-reset the output resolution); and a PANEL LOCK button  User-friendly AP for Text Overlay support  Firmware Upgrade – Ethernet-based, via a user-friendly software upgrade tool  An OSD (On-Screen Display) – for making adjustments VP-732 – Overview...

  • Page 12: Defining The Vp-732 Presentation Switcher/Dual Scaler

     Via the Ethernet using built-in user-friendly Web pages The VP-732 is housed in a 19” 1U rack mountable enclosure, with rack “ears” included, and is fed from a 100-240 VAC universal switching power supply. Defining the VP-732 Presentation Switcher/Dual Scaler This section defines the VP-732.

  • Page 13: Figure 1: Vp-732 Presentation Switcher/Dual Scaler Front Panel

    Figure 1: VP-732 Presentation Switcher/Dual Scaler Front Panel Feature Function IR Receiver Receives signals from the remote control transmitter Lights red when the unit accepts IR remote commands PROGRAM UNIV 1 Press to select the computer graphics/composite video / s-Video / component video source (configured via the OSD...
  • Page 14 Feature Function ENTER Button Press to move to the next level in the OSD screen or to accept a new parameter Decreases the range by one step in the OSD screen or moves to the previous level in the OSD screen. Button Decreases the volume level, when not in the OSD menu Moves up one step (in the same level) in the OSD screen, or moves to the previous slide when running a slideshow...

  • Page 15: Figure 2: Vp-732 Presentation Switcher/Dual Scaler Rear Panel

    Figure 2: VP-732 Presentation Switcher/Dual Scaler Rear Panel Feature Function HDMI IN 1 Connector Connect to the HDMI 1 source (from 1 to 4) UNIV IN 1 15-pin HD Connector Connects to the video source that can be computer graphics, composite video, s-Video (Y/C)

  • Page 16: Installing In A Rack

    Installing in a Rack This section provides instructions for rack mounting the unit. VP-732 - Installing in a Rack...

  • Page 17: Connecting The

    Connecting the VP-732 Always switch off the power to each device before connecting it to your VP-732. After connecting your VP-732, connect its power and then switch on the power to each device. To connect the VP-732 as illustrated in the example in...
  • Page 18 We recommend that you use only the power cord that is supplied with this machine If required, connect:  A PC via RS-232, see Section 5.2  The ETHERNET port, see Section 5.3 The USB connector, audio sources and acceptors, and power cord are not shown in Figure VP-732 - Connecting the VP-732...

  • Page 19: Figure 3: Connecting To The Vp-732 Rear Panel

    Figure 3: Connecting to the VP-732 Rear Panel VP-732 – Connecting the VP-732...

  • Page 20: Universal Connector Pinout

    Note that PINs 5, 6, 7, 8 and 10 are GND Connecting to the VP-732 via RS-232 You can connect to the VP-732 via an RS-232 connection using, for example, a PC. Note that a null-modem adapter/connection is not required.

  • Page 21: Connecting The Vp-732 Via The Ethernet Port

    5.3.1 Connecting the Ethernet Port Directly to a PC You can connect the Ethernet port of the VP-732 directly to the Ethernet port on your PC using a crossover cable with RJ-45 connectors. This type of connection is recommended for identifying the VP-732 with the factory configured default IP address.

  • Page 22: Figure 5: Local Area Connection Properties Window

    Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4 (TCP/IPv4) depending on the requirements of your IT system. Click Properties. The Internet Protocol Properties window relevant to your IT system appears as shown in Figure 6 Figure VP-732 - Connecting the VP-732...

  • Page 23: Figure 6: Internet Protocol Version 4 Properties Window

    Figure 6: Internet Protocol Version 4 Properties Window Figure 7: Internet Protocol Version 6 Properties Window VP-732 – Connecting the VP-732...

  • Page 24: Figure 8: Internet Protocol Properties Window

    Click Close. 5.3.2 Connecting the Ethernet Port via a Network Hub or Switch You can connect the Ethernet port of the VP-732 to the Ethernet port on a network hub or using a straight-through cable with RJ-45 connectors. 5.3.3 Control Configuration via the Ethernet Port To control several units via Ethernet, connect the Master unit (Device 1) via the Ethernet port to the Ethernet port of your PC.

  • Page 25: Connecting The Balanced/Unbalanced Stereo Audio Output

    Connecting the Balanced/Unbalanced Stereo Audio Output Figure 10: Connecting an Unbalanced Figure 9: Connecting the Balanced Stereo Audio Acceptor to the Balanced Stereo Audio Output Output VP-732 – Connecting the VP-732...

  • Page 26: Presentation Switcher / Scaler Buttons

    Presentation Switcher / Scaler Buttons The VP-732 includes the following front panel buttons:  Ten PROGRAM INPUT selector buttons  Ten PIP/PREVIEW INPUT selector buttons  A PREVIEW MODE button to toggle between the PIP and PREVIEW modes  PROGRAM and PREVIEW separate BLANK and FREEZE buttons ...

  • Page 27: Preview/Program Operation Mode

    PIP input appears as an insert over the program display when the PIP is ON (see Section 6.3). The VP-732 has several outputs: two PROGRAM outputs (HDMI 2 and DP) one PREVIEW output (PC) and HDMI 1 which can be assigned to be either PROGRAM or PREVIEW (see Section 7.3).
  • Page 28 Select On/Off and set the PIP to ON. Select Source and press ENTER. Use the buttons to select the PIP Source from the drop-down list box, and press ENTER. To exit the OSD menu, press the MENU button. VP-732 - Presentation Switcher / Scaler Buttons...

  • Page 29: Locking And Unlocking The Front Panel

    Locking and Unlocking the Front Panel To prevent changing the settings accidentally or tampering with the unit via the front panel buttons or the remote control transmitter, lock your VP-732. Unlocking releases the protection mechanism. When the front panel is locked, control is still available via RS-232 and/or the Ethernet.

  • Page 30: The Infrared Remote Control Transmitter

    This IR remote control transmitter is compatible with various Kramer machines, therefore not all its buttons are applicable to the VP-732. The table below defines only the buttons that are relevant to the VP-732; the functionality of the other buttons is marked N/A.

  • Page 31: Configuring The Vp-732 Via The Osd Menu Screens

    Screens The VP-732 uses an on-screen display (OSD) menu for system configuration. The menu appears as an overlay over any images that are output from the VP-732. There are seven sub-menus that are used to configure the VP-732. You can activate and navigate these menus from the front panel buttons, or from the IR remote control.

  • Page 32: The Input Screen

    We recommend that you update the Hpos, Vpos, Frequency and Phase values (in the Fine-tune OSD menu) only after Auto Image is complete (if necessary). Enabled for VGA VP-732 - Configuring the VP-732 via the OSD MENU Screens...

  • Page 33: The Picture Screen

    Mosquito NR – Set the Mosquito noise reduction level: Off, Low, Medium, High Enabled for analog inputs only Set the block noise reduction level: Off, On Enabled for analog inputs only VP-732 – Configuring the VP-732 via the OSD MENU Screens...

  • Page 34: The Output Screen

    Set zoom to 100% 150%, 200%, 225%, 250%, 275%, 100% 300%, 325%, 350%, 375%, 400% or click custom to set the custom zoom and enable Zoom H-Pan and Zoom V- VP-732 - Configuring the VP-732 via the OSD MENU Screens...
  • Page 35 Set the HDMI 2 output type to Auto, HDMI or DVI Type Test Set the test pattern to Colorbar, SMPTE, Greyscale, Picture Border, Pattern Multiburst, Ramps, H-pattern, Setup, or set to Off VP-732 – Configuring the VP-732 via the OSD MENU Screens...
  • Page 36 You can configure the aspect ratio of any output image to fit your application. The VP-732 offers six different aspect ratio settings: Best Fit, Letterbox, Follow Output, Virtual Wide, Follow Input, and Custom. Here is how each of these settings works.

  • Page 37: The Pip Screen

    Set the vertical position of the PIP on the display: 0 – 128 V-Position H-Size – Set custom size: 1 – 255 (up to 960 pixels) Custom V-Size – Set custom size: 1 – 255 (up to 540 pixels) VP-732 – Configuring the VP-732 via the OSD MENU Screens...

  • Page 38: The Audio Screen

    Video in the Input Source menu. When Off selecting a different video signal will not change the audio setting and it can be selected via the Input Source menu separately VP-732 - Configuring the VP-732 via the OSD MENU Screens...

  • Page 39: The Setup Screen

    Frame Lock mode unless all sources are frame synchronized  If VP-732 can lock the input then the output will follow  If VP-732 cannot lock the input, then the output will not change. The info menu will display one of the...
  • Page 40 Default When changing the output resolution (not including Native HDMI and Custom 1 to 4), if the new output resolution can be locked, VP-732 locks it. If not, it will be unlocked When changing the output resolution to Native, HDMI...
  • Page 41 3. Click Logo Download item. The BMP image appears 4. Select the BMP file and press the Enter button When Custom is selected in the Logo item menu this logo will appear after powering up the device VP-732 – Configuring the VP-732 via the OSD MENU Screens...
  • Page 42 VP-732 When selecting Logo you need to download the Txtlogo.BMP file to the USB and connect it to the VP-732 (See Section 7.6.3.1) Firmware For factory use Default Download Path VP-732 - Configuring the VP-732 via the OSD MENU Screens...

  • Page 43: Figure 20: Text Overlay Application Screen

    Using Text Overlay The text overlay feature is accessed via the Application Program (AP). Running this AP with the PC connected to the VP-732 lets you display text over the screen, with features including text color and speed, transparency, text position and repetition.
  • Page 44 IP Address When selected Set the IP address of the device and the port Current Status Indicates whether there is a valid connection to the VP-732 Scrolling Mode Area Speed Dropdown Box Set the speed at which the text moves on the display...
  • Page 45 Reads the EDID file from the acceptor that is connected to the VGA output. The EDID is stored as a custom output resolution. This allows, for example, automatic handling of LED screens that support very low non-standard resolutions VP-732 – Configuring the VP-732 via the OSD MENU Screens...

  • Page 46: Figure 21: Active Video Functions

    For UNIV 1, UNIV 2, UNIV 3, UNIV 4 Default Set the default EDIDs on the inputs Default Copy VGA Out Copy the EDID from the sink on the PC output to the input VP-732 - Configuring the VP-732 via the OSD MENU Screens...

  • Page 47: The Info Screen

    Preview Source, PIP Source, Program Output, Preview Output, HDMI Output, Sync Mode, MCU Version, OSD Version, FPGA Version, Slave Version CPLD IO Version, CPLD KPD Version, Dynamic IP/Static IP. Figure 22: Information Screen VP-732 – Configuring the VP-732 via the OSD MENU Screens...

  • Page 48: Firmware Upgrade

    Kramer Web site at http://www.kramerelectronics.com/support/downloads.asp You can upgrade the VP-732 via the VP Download tool, which can be downloaded from our Web site. After downloading this upgrade tool: Connect the VP-732 to your PC via the Ethernet.

  • Page 49: Using The Embedded Web Pages

    Using the Embedded Web Pages The Web pages let you control the VP-732 via the Ethernet. The Web pages include all the OSD items and more, and are accessed using a Web browser and an Ethernet connection. Note that the Web page features are described in more detail in the OSD...
  • Page 50 The EDID management page (see Section 9.8)  The Advanced Settings page (see Section 9.9)  The Custom Resolutions page (see Section 9.10)  The Security page (see Section 9.11)  The About page (see Section 9.12) VP-732 - Using the Embedded Web Pages...

  • Page 51: The Routing & Scaling Page

    Routing & Scaling page selected and below a list of all the other available Web pages. Figure 24: The Routing & Scaling Page with Web page list on the left Note that the Web pages list on the left automatically hides itself when the page is accessed: VP-732 – Using the Embedded Web Pages...

  • Page 52: Figure 25: The Routing & Scaling Page - Program Window

    The example in Figure 25 value below shows the maximum allowed value 15 selected which lets you set the volume up to 15 only. VP-732 - Using the Embedded Web Pages...

  • Page 53: Figure 26: The Routing & Scaling Page - Main And Pip Windows

    Preview mode (PREVIEW front panel button is illuminated). In the Preview mode you can select the preview input, set the size and position of the Preview image and so on. VP-732 – Using the Embedded Web Pages...

  • Page 54: Figure 27: The Preview Routing & Scaling Page - Disabled In Pip Mode

    Figure 27: The Preview Routing & Scaling Page – Disabled in PIP Mode Figure 28: The Preview Routing & Scaling Page – Preview Mode Click the Follow program button to have the preview follow the program input. VP-732 - Using the Embedded Web Pages...
  • Page 55 The Routing & Scaling main area shows a depiction of the display which can show a single window (shown in Figure 25) or some variation of a MAIN window and a PIP window (one image over another), as illustrated in Figure VP-732 – Using the Embedded Web Pages...

  • Page 56: Figure 29: The Routing & Scaling Page - Single Program/Preview Window

    When in the PIP mode, the PIP image can be moved in any direction by clicking and moving the mouse and sized by moving the right and bottom edges of the image. Figure 30: The Routing & Scaling Page – Moving the PIP Window VP-732 - Using the Embedded Web Pages...

  • Page 57: Figure 31: The Routing & Scaling Page - Selecting The Output Resolution

    For example, if the MAIN window displays HDMI 2 and the PIP window displays UNIV 1, these inputs swap places when clicking the SWAP button, so the MAIN window will now show UNIV 1 and the PIP window will show HDMI 2 (see Figure VP-732 – Using the Embedded Web Pages...

  • Page 58: Figure 32: The Routing & Scaling Page -Swapping Inputs

    Figure 32: The Routing & Scaling Page –Swapping Inputs VP-732 - Using the Embedded Web Pages...

  • Page 59: Figure 33: The Routing & Scaling Page - Program Lower Buttons Bar

    Select one of the four standard setups. You can customize the size of each window by using the arrows. Click to toggle between PIP and single window Select freeze and/or blank effects Select a test pattern VP-732 – Using the Embedded Web Pages...

  • Page 60: Figure 35: The Routing & Scaling Page - Storing And Recalling A Preset

    Click the pen icon on the input label to edit the input. The Web page moves to the Input Settings page (see Section 9.4). Figure 37: The Routing & Scaling Page – Editing an Input VP-732 - Using the Embedded Web Pages...

  • Page 61: The Device Settings Page

    After changing the IP number, you need to reload the Web page with the new IP number 9.3.2 The Information Window To access the information window, click the icon on the lower right side of the page. Click it once more to close the INFO window. VP-732 – Using the Embedded Web Pages...

  • Page 62: Figure 39: The Device Settings Page - The Information Window

    Figure 39: The Device Settings Page – the Information Window 9.3.3 Factory Reset Click the Factory reset button to reset the device. The following window appears: Figure 40: The Device Settings Page – Factory Reset Click OK to start factory reset. VP-732 - Using the Embedded Web Pages...

  • Page 63: The Input Settings Page

    Set auto switching to On or Off Source type (UNIV) Set the type of the analog source (VGA/Component/YC/Video), disabled if the selected input is not UNIV, see Section 7.1 HDCP (HDMI & Set to ON or OFF DisplayPort) VP-732 – Using the Embedded Web Pages...
  • Page 64 Auto Image Section 7.6 Program Volume Set the selected input program volume Preview Volume Set the selected input preview volume You can set the source label by typing the label name and saving it: VP-732 - Using the Embedded Web Pages...

  • Page 65: The Output Settings Page

    Set the test pattern to Colorbar, SMPTE, Greyscale, Picture Border, Multiburst, Ramps, H-pattern, Setup, or set to Off Program/Preview Use to set the Program/Preview output volume. audio sliders note that in the PIP mode only the Program audio slider appears VP-732 – Using the Embedded Web Pages...

  • Page 66: The Audio Settings Page

    Program Output Set the program output volume Volume Note that when in the PIP mode only the Program audio output slider appears (see Figure 44 Figure 44: The Audio Settings Page (PIP Mode) VP-732 - Using the Embedded Web Pages...

  • Page 67: The Miscellaneous Video Settings Page

    Frame Latency Set to Best Quality or Fast, see Section 7.6 Hot Plug Set Hot Plug On or Off for HDMI1 to HDMI 4, DisplayPort 1 and Handshaking DisplayPort 2, see Section 7.6 VP-732 – Using the Embedded Web Pages...

  • Page 68: The Edid Management Page

    DP and VGA), from a list of default resolutions or from a file in your PC (Browse). The selected EDID can be copied to a selected input. Figure 46: The EDID Page Figure 47 shows how to select a resolution from the list and select an input: VP-732 - Using the Embedded Web Pages...

  • Page 69: Figure 47: The Edid Page - Selecting A Resolution To Copy To An Input

    To copy, click the Copy button: Figure 48: The EDID Page – Copying the EDID Figure 47 shows how to select one of the outputs from the list and select an input. To copy, click the Copy button: VP-732 – Using the Embedded Web Pages...

  • Page 70: Figure 49: The Edid Page - Copying From An Output

    Figure 49: The EDID Page – Copying from an output VP-732 - Using the Embedded Web Pages...

  • Page 71: The Advanced Settings Page

    Select MENU ONLY (locks only the menu) so you can still use the Lock Mode INPUT buttons on the front panel even when the lock button is on. select ALL to also lock the INPUT buttons VP-732 – Using the Embedded Web Pages...

  • Page 72: The Custom Resolutions Page

    52) or type it in manually. You can save up to four custom settings each for the input and the output (see Sections 0 and 0). Figure 51: The Custom Resolutions Page Figure 52: The Custom Resolutions Page – Current Parameters VP-732 - Using the Embedded Web Pages...

  • Page 73: The Security Page

    Figure 53: The Security Page 9.12 The About Page The VP-732 About page lets you view the Web page version and Kramer Electronics Ltd details. Figure 54: The About Page VP-732 – Using the Embedded Web Pages...

  • Page 74: Technical Specifications

    2.45kg (5.4lbs) approx. rack “ears”, IR remote control, 2 sets of C-SF/2RVM-0.5 cables, power cord INCLUDED ACCESSORIES: Specifications are subject to change without notice For the most updated resolution list, go to our Web site at http://www.kramerelectronics.com VP-732 - Technical Specifications...

  • Page 75: Default Communication Parameters

    800x600 VESA 1280x1024 VESA VESA Reduced 800x600 VESA 1366x768 blanking 832x624 Mac16 1366x768 VESA VESA Reduced 1024x768 VESA 1440x900 blanking 1024x768 VESA 1440x900 VESA 1024x768 VESA 1400x1050 VESA 1024x768 Mac19 1400x1050 VESA 1024x768 VESA 1600x900 VESA VP-732 – Technical Specifications...
  • Page 76 Technical Specifications of the Component Input Signal (for Program and Preview/PIP) Resolution Vertical Frequency (Hz) Remark 1080i YPbPr 1080i YPbPr 1080p YPbPr 1080p YPbPr 720p YPbPr 720p YPbPr 480i YPbPr 480p YPbPr 576i YPbPr 576p YPbPr VP-732 - Technical Specifications...

  • Page 77: Tables Of Supported Output Resolutions

    VESA 800x600 1920x1080 VESA VESA 800x600 VESA 1920x1200 Reduced blanking 800x600 VESA 1680x1050 VESA 1024x768 1080i Comp/YPbPr 1024x768 VESA 1080i 1024x768 VESA 720p 1280x720 VESA 720p 1280x768 480p 1280x768 VESA 576p 1280x800 VESA 1080p 1280x1024 1080p VP-732 – Technical Specifications...
  • Page 78 VESA 576p 1280x1024 VESA 1080p 1366x768 1080p 1366x768 VESA 480p 59.94 1400x1050 720p 59.94 1400x1050 VESA 1080i 59.94 1600x900 VESA 1080p 23.98 1600x1200 1080p 1600x1200 VESA 1080p 29.97 1920x1080 VESA 1080p 59.94 VESA 1920x1200 Reduced blanking VP-732 - Technical Specifications...

  • Page 79: Communication Protocol

    Example: get current Input 1 Source Type Send: Y113CR Reply: Z1103CRLF > Definition: : ASCII Code 0x20 CR: Ascii Code 0x0D CRLF : Ascii Code 0x0D+0x0A Go to http://www.kramerav.com/downloads/VP-732 to check for the latest VP-732 communication protocol. VP-732 – VP-732 Communication Protocol...

  • Page 80: Command List

    1: On If PIP is On, Preview will turn off PIP 0: Off Power 1: On Program Mute key function Save key --- Open / Close Setup page Recall key --- Open / Close Setup page VP-732 - VP-732 Communication Protocol...
  • Page 81 Picture Color 0~360 CVBS/YC Picture Hue 0~240 HDMI/VGA/Component 0~100 Picture Sharpness Picture Temporal NR 0: Off HDMI input is disabled. 1: Low Analog input, if pixel output > 74.25MHz will be 2: Medium disabled 3: High VP-732 – VP-732 Communication Protocol...
  • Page 82 32: 3840x2160@25Hz 33: 3840x2160@29_97Hz 34: 3840x2160@30Hz 35: 4096x2160@24Hz 36: 480p@60Hz 37: 576p@50Hz 38: 720p@50Hz 39: 720p@60Hz 40: 1080i@50Hz 41: 1080i@60Hz 42: 1080p@50Hz 43: 1080p@60Hz 44: 1080p@24Hz 45: 480P@59.94Hz 46: 720P@59.94Hz 47: 1080i@59.94Hz 48: 1080P@23.98Hz 49: 1080P@29.97Hz VP-732 - VP-732 Communication Protocol...
  • Page 83 Aspect Ratio should be Custom Aspect Ratio Custom V-Zoom -8 ~ 8 Zoom != 100% is disabled Aspect Ratio should be Custom 0: 100% Zoom 1: 150% (Aspect ratio = Custom is disabled) 2: 200% VP-732 – VP-732 Communication Protocol...
  • Page 84 0: 1/25 PIP Size 1: 1/16 2: 1/9 PIP On is enabled 3: 1/4 Pip Type = PIP is enabled 4: Custom PIP H-Position (available when PiP is On and PIP 0 ~ 128 Type=PIP) VP-732 - VP-732 Communication Protocol...
  • Page 85 -24~0~+24 Picture. HDMI1 output is set to Follow Preview Audio Preview Input Volume is available when the: Preview (VGA) output resolution is NOT set to Single Picture. -10~10 HDMI1 output is set to Follow Preview VP-732 – VP-732 Communication Protocol...
  • Page 86 8: USB 0: Off Setup - Frame Lock 1: On 0: Manual Setup - Auto Image 1: Auto 0: Seamless Setup - Switching Mode 1: Fast 0: Best Quality Setup - Frame Latency 1: Fast VP-732 - VP-732 Communication Protocol...
  • Page 87 Parameter *7, Reboot after setting IP Address / Function IP1 Subnet /Gateway 0~255 0~255 0~255 0~255 Setup - IP Address(DHCP = Off) 0~255 0~255 0~255 0~255 Setup - Subnet Mask(DHCP = Off) 0~255 0~255 0~255 0~255 Setup - Gateway(DHCP = Off) VP-732 – VP-732 Communication Protocol...
  • Page 88 Advanced Misc – Freeze 1: Freeze 2: Mute 0: Follow Output Advanced Misc – HDCP 1: Follow Input 0: Off 1: On Advanced Misc – Overscan Advanced Misc – Overlay text and logo should follow 0: Off VP-732 - VP-732 Communication Protocol...
  • Page 89 Advance Output Mode: HP(temp value, unless to run the Output mode save) 1: Positive polarity Advance Output Mode: VT(temp value, unless to run 384~2047 the Output mode save) Advance Output Mode: VW(temp value, unless to run 2~(HS-13) the Output mode save) VP-732 – VP-732 Communication Protocol...
  • Page 90 HDMI2 Copy HDMI1 Out Advance Input EDID: HDMI2 2: Advance Input EDID: HDMI2 Copy HDMI2 Out 3: Advance Input EDID: HDMI2 Copy DP Out 0: Default Advance Input EDID: HDMI2 Select Modeline 1: 1024x768 60 2: 1280x800 60 VP-732 - VP-732 Communication Protocol...
  • Page 91 HDMI4 Copy DP Out 0: Default 1: 1024x768 60 2: 1280x800 60 3: 1280x1024 60 4: 1366x4768 60 Advance Input EDID: HDMI4 Select Modeline 5: 1440x900 60 6: 1400x1050 60 7: 1600x900 60 8: 1600x1200 60 VP-732 – VP-732 Communication Protocol...
  • Page 92 4: 1366x4768 60 5: 1440x900 60 6: 1400x1050 60 7: 1600x900 60 Advance Input EDID: DP2 Select Modeline 8: 1600x1200 60 9: 1680x1050 60 10: 1920x1080 60 11: 1920x1200 60(RB) 12: 720P 50 13:720P 60 14:1080P 50 VP-732 - VP-732 Communication Protocol...
  • Page 93 6: 1400x1050 60 7: 1600x900 60 8: 1600x1200 60 9: 1680x1050 60 10: 1920x1080 60 11: 1920x1200 60(RB) 0: Advance Input EDID: UNIV4 Default Advance Input EDID: UNIV4 1: Advance Input EDID: UNIV4 Copy PC output VP-732 – VP-732 Communication Protocol...
  • Page 94 32: 1280x1024 76 Sun 33: 1280x1024 85 34: 1366x768 60 R 35: 1366x768 60 36: 1440x900 60 R 37: 1440x900 60 38: 1400x1050 60 39: 1400x1050 75 40: 1600x900 60 R 41: 1600x1200 60 42: 1680x1050 60 R VP-732 - VP-732 Communication Protocol...
  • Page 95 13: 1024x768 60 14: 1024x768 70 15: 1024x768 75 16: 1024x768 75 Mac19 17: 1024x768 85 18: 1024x800 84 Sun 19: 1152x864 75 20: 1152x870 75 Mac21 21: 1152x900 66 Sun 22: 1152x900 76 Sun VP-732 – VP-732 Communication Protocol...
  • Page 96 206: PAL-60 250: No Input detected 251: Not supported 0: 640x480 60 1: 640x480 67(Mac13) 2: 640x480 72 3: 640x480 75 PIP Input status 4: 640x480 85 5: 720x400 70 6: 720x400 85 7: 800x600 56 VP-732 - VP-732 Communication Protocol...
  • Page 97 150: 480i 60 151: 480p 60 152: 576i 50 153: 576p 50 154: 720p 50 155: 720p 60 156: 1080i 50 157: 1080i 60 158: 1080p 24 159: 1080p 50 160: 1080p 60 200: NTSC 201: PAL VP-732 – VP-732 Communication Protocol...
  • Page 98 102: 720P 50, 103: 720P 60, 104: 1080i 50, 105: 1080i 60, 106: 1080P 50, 107: 1080P 60, 108: 1080P 24, 109: 480P 59.94 110: 720P 59.94 111: 1080i 59.94 112: 1080P 23.98 113: 1080P 29.97 VP-732 - VP-732 Communication Protocol...
  • Page 99 3 : Preview Mute 4 : Preview Freeze & Mute 5 : Preview Freeze 6 : Preview Blank & Freeze & Mute 7 : Preview Blank & Freeze 0: Best Fit Preview Aspect Ratio 1: Letterbox VP-732 – VP-732 Communication Protocol...
  • Page 100 Preview Output Positioning – V Start 0 ~ A Preview Output Positioning – V End A ~ B Preview Output Positioning – V Position 0 ~ A Preview Output Positioning – V Size A ~ B VP-732 - VP-732 Communication Protocol...

  • Page 102: Safety Warning

    SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback.
