ASSEMBLY

To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly
requires two persons. Set the treadmill in a cleared area and remove the packing materials; do not dispose of the
packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with
high-performance lubricant. During shipping, lubricant may be transferred to the top of the walking belt or to the
shipping carton. This is a normal condition and does not affect treadmill performance. If there is lubricant on top
of the walking belt, wipe it off with a soft cloth and mild, non-abrasive cleaner.
Assembly requires the included hex keys
mallet , adjustable wrench
To identify assembly hardware, see the drawings below. The number in parentheses below each drawing is the
key number of the part, from the PART LIST starting on page 26. The number following the parentheses is the
quantity used in assembly. To avoid damaging plastic parts, do not use power tools for assembly.
Console Bolt (2)–2
Handrail Bolt (9)–4
Wheel Bolt/Upright Bolt (4)–6
Frame Bolt (1)–2
1. Attach a Wheel (74) to one side of the Base (37)
with a Wheel Bolt (4), two Wheel Spacers (94),
and a 3/8" Jam Nut (5). Do not overtighten the
3/8" Jam Nut; the Wheel should turn freely. If
necessary, use needlenose pliers to hold the
Wheel Spacers.
Attach the other Wheel (74) to the other side
of the Base (37) in the same way.
Upright Bolt (4)–4
Wheel Bolt (5)–2
1/2" Screw
(83)–8
and your own phillips screwdriver
No. 8 x 3/4" Screw
(10)–2
3 1/2" Bolt (33)–4
Screw (90)–2
1 1/2" Screw (66)–4
, and needlenose pliers
3/4" Screw
(3)–6
3/8" Jam Nut (5)–2
Wheel Spacer
(94)–4
1
74 94
94
4
6
1/2" Screw (119)–1
.
1/4" Star Washer
(8)–2
Flat Washer
(29)–4
Handrail Star
Washer (11)–4
Upright Washer
(7)–2
Upright Star
Frame Nut (90)–2 Washer (6)–8
74
94
5
37
5
, rubber
94
4
