- Page 1 CrystalView EX5 Quadro CATx Extender INSTALLATION AND OPERATIONS MANUAL 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
- Page 3 Limited Warranty Rose Electronics warrants the CrystalView EX5 Quadro to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
- Page 4 FCC/IC STATEMENTS, EU DECLARATION OF CONFORMITY FCC Radio Frequency Interference This device complies with FCC Part 15 Class A. of the FCC rules; operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Table Of Contents
Disclaimer ...................... 2 System Introduction ..................2 Features ......................3 Package Contents ..................3 Additional Installation Items ................4 Rose Electronics web site ................4 Product Registration ..................4 System Overview ................... 4 Models ......................5 Transmitter - Front Panel ................6 Transmitter - Rear panel Connectors ............ -
Page 6: Disclaimer
System Introduction Thank you for choosing the CrystalView EX5 Quadro extender from Rose Electronics for your remote accessing needs. The CrystalView EX5 Quadro system consists of a Transmitter unit and a Receiver unit. The Transmitter unit connects to your computer’s DVI-D and USB Type A connectors using... -
Page 7: Features
* CAT5e or better cable, Solid core CAT6 STP cable is recommended Package Contents Transmitter unit Receiver unit 5V, 3A power adapter (Transmitter) 5V, 3A power adapter (Receiver) Product Manual CrystalView EX5 Quadro Installation and Operations Manual... -
Page 8: Additional Installation Items
System Overview The CrystalView EX5 Quadro is a very versatile and flexible system that can be easily and quickly installed. You can position your computer anywhere within 330 feet of the Receiver unit and access and control it as if you were directly connected to the computer. -
Page 9: Models
Power (+5V / 3A) Receiver – Front View Indicators Power Link Video Receiver – Rear View Connectors DVI-D Out (4) Prog (4) USB Type A (3) Link (5) Audio Power (+5V / 3A) Figure 1. Models CrystalView EX5 Quadro Installation and Operations Manual... -
Page 10: Transmitter - Front Panel
USB input from Host computer Link (RJ45) Connection for a CAT5e or better cable to the Receiver unit Audio Audio input from Host computer Power +5V, 3A power adapter Table 1. Transmitter Indicators / Connectors CrystalView EX5 Quadro Installation and Operations Manual... -
Page 11: Receiver - Front Panel
Connection (3) for remote USB devices Link (RJ45) Connection for a CAT5e or better cable to the Transmitter unit Audio Audio output to console speaker input Power +5V, 3A power adapter Table 2. Receiver Indicators / Connectors CrystalView EX5 Quadro Installation and Operations Manual... -
Page 12: System Installation
INSTALLATION System Installation Before installing the CrystalView EX5 Quadro, pre-plan the layout of the computer, the Transmitter, the Receiver, and the equipment that will be connected to the Receiver. The Transmitter and Receiver units should be in a location that is easily accessible. The CAT5e cable should be routed away from equipment or environments that can cause interference with the data transmission between the Transmitter and Receiver. -
Page 13: Receiver Installation
If a Link LED is off, the CAT5e cable between the Transmitter and Receiver is not connected. The Power LED should be solid green. If it is off, the system is not ready. CrystalView EX5 Quadro Installation and Operations Manual... -
Page 14: Connecting Usb Devices
If the total power is greater than 500ma, use a powered Hub to supplement the power to the devices. The CrystalView EX5 Quadro is compatible with a wide variety or graphic cards, monitors, USB devices, and operating systems. System Operation... -
Page 15: System Troubleshooting
Resolution is not supported (See Appendix B) The CrystalView EX5 Quadro Transmitter and Receiver indicators will provide information about the operation, connectivity and data transmission. Observe these indicators and refer to Table 1 and Table 2 for a description of the indicator states. -
Page 16: Product Safety
for this Unit. Use only a grounded (three-wire) electrical outlet. Use only the power adapter provided with the CrystalView EX5 Quadro . Keep objects that might damage this Unit and liquids that may spill, clear from this Unit. Liquids and foreign objects might come in contact with voltage points that could create a risk of fire or electrical shock. -
Page 17: Maintenance And Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 18: Appendix A - General Specifications
32ºF to 104ºF (0ºC to 40ºC) Storage Temp -4ºF to 158ºF (-20ºC to 70ºC) Operating Humidity 20% to 80% non-condensing Storage Humidity 10% to 90% non-condensing Regulatory Testing FCC Part 15 Class A, CE, ICE20030 Class A CrystalView EX5 Quadro Installation and Operations Manual... - Page 20 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
