- Page 1 CrystalView EX5 CATx Extender INSTALLATION AND OPERATIONS MANUAL 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
- Page 2 Limited Warranty Rose Electronics warrants the CrystalView EX5 to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
- Page 3 FCC/IC STATEMENTS, EU DECLARATION OF CONFORMITY FCC Radio Frequency Interference This device complies with FCC Part 15 Subpart B. of the FCC rules; operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Table Of Contents
Disclaimer ...................... 1 System Introduction ..................1 Features ......................2 Package Contents ..................2 Additional Installation Items ................3 Rose Electronics web site................3 Product Registration ..................3 System Overview ................... 3 Models ......................4 Transmitter - Front Panel ................5 Transmitter - Rear panel Connectors ............ -
Page 5: Disclaimer
CAT5e or better cable. This provides access to your computer from up to 330 feet (100m) away. The CrystalView EX5 extender complies with USB 1.1 and USB 2.0 specifications and supports USB 1.1 and low bandwidth USB 2.0 devices. -
Page 6: Features
5V, 3A power adapter (Transmitter) 5V, 3A power adapter (Receiver) USB Type A to Type B cable (6 ft) DVI cable (male to male- 5 ft) Product Manual CrystalView EX5 Installation and Operations Manual... -
Page 7: Additional Installation Items
System Overview The CrystalView EX5 is a very versatile and flexible system that can be easily and quickly installed. You can position your computer anywhere within 330 feet of the Receiver unit and access and control it as if you were directly connected to the computer. -
Page 8: Models
USB Type B Link Power (+5V / 3A) Receiver – Front View Indicators Power Link Video Receiver – Rear View Connectors DVI-D Out Headphone Out Microphone In Config Link Power (+5V / 3A) Figure 1. Models CrystalView EX5 Installation and Operations Manual... -
Page 9: Transmitter - Front Panel
Reserved for company use only USB Type B USB input from Host computer (Supplied) Link (RJ45) Connection for a CAT5e or better cable to the Receiver unit Power +5V, 3A power adapter (Supplied) Table 1. Transmitter Indicators/Connectors CrystalView EX5 Installation and Operations Manual... -
Page 10: Receiver - Front Panel
USB Type A Connection (3) for remote USB devices Link (RJ45) Connection for a CAT5e or better cable to the Transmitter unit Power +5V, 3A power adapter (Supplied) Table 2. Receiver Indicators / Connectors CrystalView EX5 Installation and Operations Manual... -
Page 11: System Installation
INSTALLATION System Installation Before installing the CrystalView EX5, pre-plan the layout of the computer, the Transmitter, the Receiver, and the equipment that will be connected to the Receiver. The Transmitter and Receiver units should be in a location that is easily accessible. The CAT5e cable should be routed away from equipment or environments that can cause interference with the data transmission between the Transmitter and Receiver. -
Page 12: Receiver Installation
(Refer to Table 2 and Table 3) If the Link LED is off, the CAT5e cable from the Transmitter and Receiver are not connected. The Power LED should be solid green. If it is off the system is not ready. CrystalView EX5 Installation and Operations Manual... -
Page 13: Connecting Usb Devices
If the total power is greater than 500ma, use a powered Hub to supplement the power to the devices. The CrystalView EX5 is compatible with a wide variety or graphic cards, monitors, USB devices, and operating systems. System Operation... -
Page 14: System Troubleshooting
Check the CAT5e Link connections on the Transmitter and Receiver Video and/or USB performance is not satisfactory High amount of network traffic, reduce the number of CrystalView EX5 units on the network or reduce the network traffic. Graphic/video settings do not list the specific resolution Up to date video drivers are not installed ... -
Page 16: Product Safety
SAFETY Product Safety The CrystalView EX5 extender has been tested for conformance to safety regulations and requirements, and has been certified for international use. Like all electronic equipment, the CrystalView EX5 should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. -
Page 17: Maintenance And Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 18: Appendix A - General Specifications
32ºF to 104ºF (0ºC to 40ºC) Storage Temp -4ºF to 158ºF (-20ºC to 70ºC) Operating Humidity 20% to 80% non-condensing Storage Humidity 10% to 90% non-condensing Regulatory Testing FCC Part 15 Class A, CE, ICE20030 Class A CrystalView EX5 Installation and Operations Manual... - Page 20 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
