CrystalView Rack
TM
Installation and Operations
Manual Supplement
PC-Single 6-port
PC-Single Serial/Audio
Model CRV-6SLP
Model CRV-6SLP/AUD
PC-Dual 6-port
PC Dual Serial/Audio
Model CRV-6DLP
Model CRV-6DLP/AUD
PC-Single 12-port
Model CRV-12SLP
10707 Stancliff Road
Phone: (281) 933-7673
Houston, Texas 77099
WWW.ROSE.COM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rose electronics CrystalView Rack CRV-12SLP
Summary of Contents for Rose electronics CrystalView Rack CRV-12SLP
- Page 1 CrystalView Rack Installation and Operations Manual Supplement PC-Single 6-port PC-Single Serial/Audio Model CRV-6SLP Model CRV-6SLP/AUD PC-Dual 6-port PC Dual Serial/Audio Model CRV-6DLP Model CRV-6DLP/AUD PC-Single 12-port Model CRV-12SLP 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
-
Page 2: Package Contents
Optional power adapter (Auto-switching transformer) A remote CrystalView unit is needed for each local CrystalView used. Cables are usually ordered separately. If the package contents are not correct, contact Rose Electronics or your reseller, so the problem can be quickly resolved. About this supplement This supplement covers the installation of the CrystalView PC, Multi- unit Rackmount model. - Page 3 PC - 6 Unit model (Serial/Audio) 6-RJ45 – CAT-5 cable connection 6-DB25F – CPU / KVM connections 12-3.5mm stereo audio jacks (Audio in/out) 6-DB9F Serial cable connections PC - 6 Unit model 6-RJ45 – CAT-5 cable connection 6-DB25F – CPU / KVM connections Front Panel Rear Panel Front Panel...
- Page 4 6-RJ45 – CAT-5 cable connection 6-DB25F – CPU / KVM connections 6-HD15 Monitor PC - 6 Unit Dual model with serial/ / audio 6-RJ45 – CAT-5 cable connection 6-DB25 – CPU/KVM connections 12-MiniDin6 KBD/Mouse 6-HD15 monitor Front Panel Rear panel 12-MiniDin6 KBD/Mouse Front panel Rear panel...
- Page 5 For CAT5 cable distances less than 150 feet, the CrystalView MINI remote unit can be used. Part number and description table Part Number CRV-6SLP/AUD CRV-6SLP CRV-6DLP CRV-6DLP/AUD CRV-12SLP CAB-08UTPnnn* CAB-CXV66MMnnn* CAB-SPMMnnn* CAB-D9MFnnn* TFR-05D400FSUP Front Panel Rear Panel...
- Page 6 * nnn = cable length in feet Remote Switch Stations Remote Units Stations Local Switch 1 of 8 CPUs Local Switch 1 of 8 CPUs The above diagram shows the versatility of the CrystalView Cat5 rack. The CrystalView Cat5 Rack can connect to standalone computers or KVM switches using the appropriate cables.
- Page 7 Rack mount instructions To rack mount your CrystalView, attach the two rack mounting brackets on your Unit to the rack using the appropriate size bolts, nuts and lock washers. The following guidelines should be observed when installing. Do not exceed the operating temperature of 0 Do not block power supply vents or restrict airflow.
- Page 8 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
