5
Removal and replacement
procedures
NOTE:
HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and
then follow the on-screen instructions.
Tablet component replacement procedures
CAUTION:
service provider. Accessing these parts can damage the tablet and void the warranty.
This chapter provides removal and replacement procedures for authorized service provider only parts.
There are as many as 20 screws that must be removed, replaced, and/or loosened when servicing the
tablet. Make special note of each screw size and location during removal and replacement.
Back cover
Description
Back cover
7-in., IPS, LCD, TouchScreen display panel assembly (includes display panel cable and
TouchScreen cable)
Before disassembling the tablet, follow these steps:
1.
Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2.
Disconnect the power from the tablet by unplugging the power cord from the tablet.
3.
Disconnect all external devices from the tablet.
Remove the back cover:
12
Chapter 5 Removal and replacement procedures
Tablet components described in this chapter should only be accessed by an authorized
Spare part number
751302-001
751301-001
