Miscellaneous parts

Component
10-W, 5-V, 2-A, USB, AC adapter
For use only in Europe and South Korea
For use only in India
For use only in the People's Republic of China
HP Slate7 VoiceTab equipped with a 7-in., IPS, LCD, TouchScreen display panel, a Marvel
PXA1088 1.20-GHz quad core processor, 1.0-GB LP-DDR2 system memory, and a 16.0-
GB eMMC solid state drive
Screw Kit
USB extension cable

Sequential part number listing

Spare part number
744423-005
744423-006
744423-009
751300-001
751301-001
751302-001
751304-001
751305-001
751307-001
751308-001
751309-001
751310-001
751312-001
751313-001
751314-001
6 Chapter 3 Illustrated parts catalog
Description
10-W, 5-V, 2-A, USB, AC adapter for use only in India (includes duck head adapter)
10-W, 5-V, 2-A, USB, AC adapter for use only in the People's Republic of China (includes
duck head adapter)
10-W, 5-V, 2-A, USB, AC adapter for use only in Europe and South Korea (includes
duck head adapter)
System board equipped with a Marvel PXA1088 1.20-GHz quad core processor, 1.0-GB LP-DDR2
system memory, and a 16.0-GB eMMC solid state drive (includes left and right speakers and
vibrator module)
7-in., IPS, LCD, TouchScreen display panel assembly
Back cover
Middle frame
Power/volume button board (includes cable and double-sided adhesive)
Speaker/Vibrator Module Kit (includes left and right speakers, cables, and grommets and vibrator
module and cable)
2.0-MP front-facing webcamera (includes cable and double-sided adhesive)
5.0-MP rear-facing webcamera (includes cable)
FPC cable (includes double-sided adhesive)
Battery, 4100-mAh, Li-ion (includes cable and double-sided adhesive)
Screw Kit
Proximity/ambient light sensor board (includes cable and double-sided adhesive)
Spare part number
744423-009
744423-005
744423-006
751317-001
751313-001
751316-001
and 751657-001
