Front-facing webcamera

Description
2.0-MP front-facing webcamera (includes cable)
Before removing the front-facing webcamera, follow these steps:
1.
Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
a.
Middle frame (see
b.
FPC cable (see
c.
System board (see
Remove the front-facing webcamera:
1.
Turn the system board upside down with the top toward you.
2. Release the ZIF connector (1) to which the front-facing webcamera cable is attached, and then
disconnect the front-facing webcamera cable from the system board.
3. Remove the front-facing webcamera (2).
Reverse this procedure to install the front-facing webcamera.
Back cover on page
Middle frame on page
FPC cable on page 19)
System board on page
12), and then remove the following components:
14)
23)
Front-facing webcamera
Spare part number
751308-001
25
