2. Detach the power/volume button board (2) from the display panel assembly. (The power/volume
button board is attached to the display panel assembly with double-sided adhesive.)
3.
Remove the power/volume button board and cable.
Reverse this procedure to install the power/volume button board.

Rear-facing webcamera

Description
5.0-MP rear-facing webcamera (includes cable)
Before removing the rear-facing webcamera, follow these steps:
1.
Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2.
Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
5. Remove the middle frame (see
Remove the rear-facing webcamera:
1. Release the zero insertion force (ZIF) connector (1) to which the rear-facing webcamera is
attached, and then disconnect the rear-facing webcamera from the system board.
Back cover on page 12).
Middle frame on page
Spare part number
753193-001
14).
Rear-facing webcamera
17
