Part Numbers

SW RGBHV switcher part numbers

Switcher
SW2 RGBHV video switcher
SW2 RGBHV A video and audio switcher
SW4 RGBHV video switcher
SW4 RGBHV A video and audio switcher
SW6 RGBHV video switcher
SW6 RGBHV A video and audio switcher
SW6 YUV A component video and digital audio switcher

Supplied accessories

Switcher
SW RGBHV switcher User's Manual
Universal Switcher Control Program
Rack mounting bracket kit (SW4 and SW6 models only)
3.5 mm 5-pole captive screw connectors

Optional accessories

Extron Part
SW2 models only
1U universal rack shelf kit
1U basic rack shelf
Table mounting bracket kit
Thru-desk mounting bracket kit
SW4 and 6 models only
Under desk mounting bracket kit
All models
KP 6 keypad remote control
IR 102 infrared remote control kit
SVHSM-BNCF adapter

Cables

When using signals with a scanning frequency of 15-125 kHz and running distances
of 100 feet or more, use RG6/Super High Resolution (RG6/SHR) or Mini High Res
(Mini HR) BNC cables for best performance. Rental and staging (RC) cable is ideal
for jobs with repeated installation and removal in high traffic areas.
BNC-5 cable is used for RGBHV cable runs and BNC-4 cable is used for RGBS,
RGsB, and component video cable runs. Plenum BNC-5 Mini HR cable is available.

Bulk cables

RG6/Super High Resolution Cable
RG6/SHR-1 bulk , 500', 1000'
RG6/SHR-4 bulk , 500'
RG6/SHR-5 bulk , 500'
BNC-4 Mini HR Cable
BNC-4 Mini HR bulk, 500', 1000'
BNC-5 Mini HR Cable
BNC-5 Mini HR bulk, 500', 1000'
SW RGB and YUV A Switchers • Specifications and Part Numbers
Part #
60-491-01
60-491-21
60-492-01
60-492-21
60-493-01
60-493-21
60-498-01
Part #
70-077-03
10-319-10
Part #
60-190-01
60-604-01
70-077-01
70-077-02
70-222-01
60-111-20
70-224-01
26-353-01
Part #
22-098-02, -03
22-099-02
22-100-02
Part #
22-032-02, -03
Part #
22-020-02, -03
A-5
