Specifications, cont'd
Audio output — SW 2/4/6 RGBHV A only
Number/signal type ................... 1 stereo, balanced/unbalanced
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 50 ohms balanced
Nominal level ............................... -20 dBV (100mV), -10 dBV (316mV), 0 dBu (1V), or +4 dBu (1.23V),
Maximum level (Hi-Z) ................ >26 dBu, balanced; >+20 dBu, unbalanced at 1%THD+N
Maximum level (600 ohm) ......... >+21 dBm, balanced; >+15 dBm, unbalanced at 1%THD+N
0 dBu = 0.775 volts (RMS). 0 dBV = 1.0V.
Control/remote — switcher
Serial control port ........................ RS-232, 9-pin female D connector (same as the contact closure port)
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations 2 = TX, 3 = RX, 5 = GND
Contact closure ............................ 9-pin female D connector (same as the RS-232 port)
Contact closure pin configurations 1 = input #1, 4 = input #2, 6 = input #3, 7 = input #4, 8 = input #5, 9 = input #6
Program control ........................... Extron's control program for Windows®
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 20 watts, internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Rack mount
SW2 RGBHV, SW2 RGBHV A
All other models .............. Yes, with included bracket kit, part #70-077-03
Enclosure type .............................. Metal
Enclosure dimensions
SW2 RGBHV, SW2 RGBHV A
All other models .............. 1.75" H x 17.5" W x 8.5" D (1U high, full rack width)
Product weight
SW2 RGBHV ..................... 2.4 lbs (1.1 kg)
SW2 RGBHV A ................ 2.5 lbs (1.1 kg)
All other models .............. 7.0 lbs (3.2 kg)
Shipping weight
SW2 RGBHV, SW2 RGBHV A
All other models .............. 12 lbs (5.4 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
A-4 SW RGB and YUV A Switchers • Specifications and Part Numbers
configurable
Extron's Simple Instruction Set™ – SIS™
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
Yes, with optional rack shelf, part #60-190-01
1.75" H x 8.75" W x 9.5" D (1U high, half rack width)
4.4 cm H x 22.2 cm W x 24.1 cm D
(Depth excludes connectors.)
4.4 cm H x 44.5 cm W x 21.6 cm D
(Depth excludes connectors.)
5 lbs (2.4 kg)
