Part Numbers and Accessories

Included Parts

Included Part
SW2 USB
SW4 USB
SW4 USB Plus
3.5 mm, 3-pole captive screw connector with strain relief
(3 for SW2 USB, 2 for SW4 USB and SW4 USB Plus)
3.5 mm, 5-pole captive screw connector with strain relief
(SW4 USB and SW4 USB Plus)
12 VDC power supply with 2-pole captive screw connector attached
IEC power cord
Clear zip ties (3)
Rubber feet, unattached (4)
SW USB Series Setup Guide
Software Products DVD

Optional Accessories

Accessory
CCR 2BLB Two-Button Contact Closure Remote
With Backlit Buttons (black, white)
CCR 4BLB Two-Button Contact Closure Remote
With Backlit Buttons (black, white)
CCR 204 Four-Button Contact Closure Remote (black)
IR 102 Remote Control Kit
SW2 VGA Series Switcher
SW4 VGA Series Switcher
PS 1210C 12 V, 1 A Desktop Power Supply
2-pole orange captive screw connectors, 10-pack
3-pole blue captive screw connectors, 10-pack

Mounting Options

These mounting kits can be purchased for the SW USB:
Mounting Option
RSU 129 (9.5" deep 1U universal rack shelf kit)
RSB 129 (9.5" deep 1U basic rack shelf)
RSU 126 (6" deep 1U universal rack)
RSB 126 (6" deep basic rack shelf)
RSF 123 (3.5" deep 1U rack shelf kit)
RSB 123 (3.5" deep 1U rack shelf)
MBU 123 Mini Under-desk Mounting Kit
Replacement
Part Number
60-952-02
60-953-02
60-954-02
100-456-01
100-457-01
Part Number
70-589-02, -03
70-588-02, -03
60-794-02
70-224-01
60-257-22
60-258-22
70-775-01
100-454-01
100-456-01
Part Number
60-190-01
60-604-02
60-190-10
60-604-11
60-190-20
60-604-21
70-212-01
