SW2 RGBHVcc &
SW2 VGAcc
TWO INPUT RGBHV & VGA-UXGA SWITCHERS
WITH CONTACT CLOSURE CONTROL
SW2 RGBHVcc
SW2 VGAcc
The Extron SW2 RGBHVcc and SW2 VGAcc are high performance, two input,
one output, active switchers for RGBHV and VGA respectively. Offering contact
closure and front panel control, both switchers are ideal for conference rooms,
classrooms, multimedia production systems, and other high resolution video
environments.
SWITCHERS
350 MHz (-3 dB) video bandwidth
SW2 RGBHVcc inputs and outputs
on female BNC connectors
SW2 VGAcc inputs and outputs on
15-pin HD female connectors
Contact closure remote control with
tally output status
1U, half rack width metal enclosure
www.extron.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Extron electronics SW2 RGBHVcc
Summary of Contents for Extron electronics SW2 RGBHVcc
- Page 1 WITH CONTACT CLOSURE CONTROL SW2 RGBHVcc SW2 VGAcc The Extron SW2 RGBHVcc and SW2 VGAcc are high performance, two input, one output, active switchers for RGBHV and VGA respectively. Offering contact closure and front panel control, both switchers are ideal for conference rooms, classrooms, multimedia production systems, and other high resolution video environments.
-
Page 2: Video Input
RGB video sources and route the selected source to video output device such as a data monitor or projector. The SW2 RGBHVcc is capable of switching a variety of high-resolution analog video signals, including RGBHV, RGBS, RGsB, and RsGsBs, as well as standard resolution NTSC, PAL, and SECAM sources in component video, S-video, or composite video.
