Reference
Information
•
•
•

Specifications

NOTE: *Appropriate DVI-D to HDMI cables or adapters are required for HDMI signal input/output.
NOTE: The SW DVI Plus Series are not HDCP compliant.
Video
Maximum data rate ........................ 4.95 Gbps (1.65 Gbps per color)
Maximum pixel clock ...................... 165 MHz
Resolution range ............................ Up to 1920x1200 or 1080p @ 60 Hz
Formats .......................................... RGB and YCbCr digital video
Standards ....................................... DVI 1.0, HDMI
Video input
Number/signal type ........................ 2, 4, 6, or 8 single link DVI-D (or HDMI*)
Connectors .................................... 2, 4, 6, or 8 female DVI-I
Equalization ................................... +6 dB or +12 dB, switch selectable for each input
Video output
Number/signal type ........................ 1 single link DVI-D (or HDMI*)
Connectors .................................... 1 female DVI-I
Audio
Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB
Frequency response ........................ 20 Hz to 20 kHz, ±0.05 dB
THD + Noise ................................... 0.01% @ 1 kHz at nominal level
S/N ................................................. >90 dB at maximum output (unweighted)
Crosstalk ........................................ <-45 dB @ 20 kHz, -72 dB @ 1 kHz or below
Stereo channel separation .............. >80 dB @ 20 Hz to 20 kHz
Audio input
Number/signal type ........................ 2, 4, 6, or 8 stereo, unbalanced
Connectors .................................... (2, 4, 6, or 8) 3.5 mm mini audio jacks (tip = L, ring = R, sleeve = GND)
Impedance ..................................... >10k ohms unbalanced, DC coupled
Nominal level ................................. -10 dBV (316 mVrms)
Maximum level ............................... +8.2 dBV, unbalanced at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Specifications
Part Numbers
Mounting the SW DVI Plus Switcher
SW DVI Plus Series • Reference Information 31 31 31
