Avtech 960H User Manual

REGULAR CAMERA USER MANUAL
It's recommended to use this camera with a DVR which supports 960H video recording.

FEATURES

1. 1/3" HR Color CCD
2. 700 TVL superior image quality
3. Further camera parameters configuration via its own OSD
4. Multilingual on-screen display menu in 4 languages (English / French / Portuguese / Spanish)
5. Built-in microphone for audio recording

PACKAGE CONTENT

‧ Camera x 1

SPECIFICATION*

Pick up Element
Number of Pixel
Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens Mount
IRIS Mode
White Balance
Gain Control
Sharpness
BLC
Digital WDR
Video Output
Microphone
Power Source (±10%)
Current Consumption(±10%)
Dimensions (mm)**
* The specifications are subject to change without notice.
960H Ultra Resolution Series
Please read the instructions thoroughly before using the product.
‧ User manual x 1
976(H) x 494(V) <NTSC> / 976(H) x 582(V) <PAL>
MANUAL: 1/50(60), FL 1/120(100), 1/250, 1/500, 1/1,000, 1/2,000,
1/5,000, 1/10,000, 1/20,000, 1/50,000, 1/100,000 sec.
‧ Wrench x 1
1/3" HR color CCD image sensor
700 TVL
0.1 Lux / F2.0
More than 48dB (AGC off)
AUTO: 1/50 (60) to 1/100,000 sec.
CS Mount
AES / VD / DD
Auto / Fixed
AGC adjustable / Fixed
Adjustable
ON / OFF
YES
1.0 Vp-p composite, 75Ω
Built-in
DC 12V
70mA
117(L) x 60(W) x 50(H)
** Dimensional Tolerance: ± 5mm
544Z
151_V0.9
