Suspend Time Out
This item sets up the timeout for Suspend mode in minutes. If the time selected
passes without any system activity, the computer will enter power-saving
Suspend mode.
Resume on RTC Alarm
The system can be turned off with a software command. If you enable this item,
the system can automatically resume at a fixed time based on the system's RTC
(realtime clock). Use the items below this one to set the date and time of the
wake-up alarm. You must use an ATX power supply in order to use this feature.
LAN/Ring Power On
The system can be turned off with a software command. If you enable this item,
the system can automatically resume if there is an incoming call on the Modem/
Ring, or traffic on the network adapter. You must use an ATX power supply in
order to use this feature.
Keyboard Power On/Wake-Up Key
If you enable this item, the system can automatically resume by pressing any
keys, hot key, power key on the keyboard, or typing in the password. You must
use an ATX power supply in order to use this feature.
PCI / Plug and Play Setup Page
This page sets up some parameters for devices installed on the PCI bus and
those utilizing the system plug and play capability.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
Primary Graphics Adapter
Share Memory Size
Allocate IRQ to PCI VGA
PCI IDE BusMaster
Primary Graphics Adapter
This item indicates if the primary graphics adapter uses the PCI or the AGP bus.
The default PCI setting still lets the onboard display work and allows the use of
a second display card installed in an AGP slot.
Share Memory Size
This item lets you allocate a portion of the main memory for theonbaord VGA
display application with several options.
Chapter 3: BIOS Setup Utility
PCI / Plug and Play Setup
PCI
32 MB
Yes Select which graphics controller
Disabled
to use as the primary boot
device.
25
Help Item
