ECS Motherboard User Manual page 43

Motherboard User's Guide
4 Select Block Size, then press <Enter> to set array block size. Lists of
valid array block sizes are displayed on a pop-up menu.
Tip
Use arrow keys to move selection bar on items and press <Enter> to select.
5 Select Start Create Process and press <Enter> to setup hard disk for
RAID system. The following confirmation appears:
The same confirmation message appears when
the Auto Setup for Performance option is selected.
Press "Y" to confirm or "N" to return to the configuration options.
RAID 1 for data protection
1 Select the second option item Array Mode, then press the <Enter> key.
The RAID system setting pop-up menu appears.
2 Select RAID 1 for data protection from the menu and press <Enter>.
Select next task from pop-up menu. The task Create only creates the
mirrored set without creating a backup. Create and duplicate creates
both mirrored set and backup.
For server systems, it is recommended to use a
lower array block size. For multimedia computer
systems used mainly for audio and video editing,
a higher array block size is recommended for
optimum performance.
38
