Advanced Setup Page

This page sets up more advanced information about your system. Handle this
page with caution. Any changes can affect the operation of your computer.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
Quick Boot
1st Boot Device
2nd Boot Device
3rd Boot Device
Try Other Boot Device
Bootup Num-Lock
Boot To OS/2 > 64 MB
AGP Aperture Size
DRAM Timing
DRAM CAS# Latency
DRAM Bank Interleave
Hyper Threading Function
Auto Detect DIMM/PCI Clk
Spread Spectrum
Max CPUID Value Limit
Execute Disable Bit
CPU TM Function
C1E Support
Intel (R) SpeedStep (tm) tech.
Venderpool Technology
DRAM Driving
Quick Boot
If you enable this item, the system starts up more quickly be elimination some
of the power on test routines.
1st Boot Device/2nd Boot Device/3rd Boot Device
Use these items to determine the device order the computer uses to look for an
operating system to load at start-up time.
Try Other Boot Device
If you enable this item, the system will also search for other boot devices if it
fails to find an operating system from the first two locations.
BootUp Num-Lock
This item determines if the Num Lock key is active or inactive at system start-
up time.
Boot To OS/2> 64MB
Enable this item if you are booting the OS/2 operating system and you have
more than 64MB of system memory installed.
AGP Aperture Size
This item defines the size of aperture if you use a graphic adapter.
DRAM Timing
This item allows you to enable or disable the DRAM timing defined by the
Serial Presence Detect electrical.
Chapter 3: BIOS Setup Utility
Advanced Setup
Enabled
Help Item
PM-IC35L040AVVN07
SS-Pioneer DVD-R0
1st Floppy Drive
Yes
Allows BIOS to skip certain
On
tests while booting. This will
No
decrease the time needed
64 MB
to boot the system.
Manual
By SPD
4-way
Ensabled
Enabled
Disabled
Disabled
Enabled
Disabled
Disabled
Disabled
Enabled
Normal
