H. Make sure the CPU fan is plugged to the
CPU fan connector. Please refer to the
CPU cooling fan user's manual for more
detail installation procedure.
Note 1: To achieve better airflow rates and heat dissipation, we suggest
that you use a high quality fan with 3800 rpm at least. CPU fan and
heatsink installation procedures may vary with the type of CPU fan/
heatsink supplied. The form and size of fan/heatsink may also vary.
Note 2: DO NOT remove the CPU cap from the socket before installing a
CPU.
Note 3: Return Material Authorization(RMA) requests will be accepted only if
the motherboard comes with the cap on the LGA775 socket.

Installing Memory Modules

This motherboard accommodates two 240-pin DIMM DDRII1~2 sockets (Dual
Inline Memory Module) for unbuffered DDR2 533 memory modules (Double
Data Rate SDRAM). DDR2 SDRAM is a type of SDRAM that supports data
transfers on both edges of each clock cycle (the rising and falling edges),
effectively doubling the memory chip's data throughput. You must install at least
one module in any of the two slots. Each module can be installed with 256 MB
to 1 GB of memory; total memory capacity is 2 GB.
