DRAM Driving
When this item is defaulted at "Normal", some DDRs might cause the problem
of booting or system stability; in that case, please set it at "High".

Features Setup Page

This page sets up some parameters for peripheral devices connected to the
system.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
OnBoard Floppy Controller
Serial Port1 Address
OnBoard IR Port
Parallel Port Address
Parallel Port Mode
ECP Mode DMA Channel
Parallel Port IRQ
OnBoard PCI IDE Controller
Onboard SATA-IDE
Audio Device
MODEM Device
Ethernet Device
OnBoard LAN Boot Rom
OnBoard USB Function
USB Function For DOS
OnBoard Floppy Controller
Use this item to enable or disable the onboard floppy disk drive interface.
OnBoard Serial Port
Use this item to enable or disable the onboard COM1 serial port, and to assign a
port address.
OnBoard IR Port
Use this item to enable or disable the onboard infrared port, and to assign a port
address.
Onboard Parallel Port
This item enables or disables the onboard LPT1 parallel port, and assigns a port
address. The Auto setting will detect and available address.
Parallel Port Mode
Use this item to set the parallel port mode. You can select Normal (Standard
Parallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port),
or EPP & ECP.
Parallel Port IRQ
Use this item to assign IRQ to the parallel port.
Parallel Port DMA
Use this item to assign a DMA channel to the parallel port.
Chapter 3: BIOS Setup Utility
Features Setup
Enabled
Help Item
3F8/IRQ4
Disabled
Allows BIOS to Enable or
378
Disable Floppy Controller.
ECP
DMA3
IRQ7
Both
IDE
Enabled
Auto
Enabled
Disabled
Enabled
Disabled
23
