Motherboard User's Guide
Supports for AGP 8X/4X, AGP v3.0 compliant with 1.5V
•
Advanced 64-bit DDR2 533 SDRAM controller
•
Note: P4M800Pro chipset can only support mixed 1024/512/256/128/
64Mb x8/16 DDR2 SDRAMs.
Supports 16-bit 66 MHz V-Link Host interface with total bandwidth of
•
1066 MB/s
Compliant with PCI 2.2 specification at 33 MHz, supporting up to 6
•
PCI masters
Integrated Serial ATA Host Controllers, supporting data transfer rates up
•
to 1.5Gb/s
Integrated Dual channel UltraDMA 133/100/66 Master Mode EIDE
•
Controller
USB 2.0 Controller, supporting up to 8 USB 2.0 ports
•
Network Controller, supporting enterprise class 100/10 Mb Fast
•
Ethernet MAC
Integrated keyboard Controller with PS2 mouse support
•
Memory Support
Two 240-pin DIMM sockets for DDR2 SDRAM memory modules
•
Support DDR2 533 DDR2 SDRAM with Maximum memory size of 2
•
GB.
Expansion Slots
Three 32-bit PCI slots
•
One 8X AGP slot
•
One CNR slot
•
Onboard IDE channels
Supports PIO (Programmable Input/Output) and DMA (Direct Memory
•
Access) modes
Supports IDE Ultra DMA bus mastering with transfer rates of 133/100/
•
66 MB/sec
Serial ATA
Two Serial ATA Connectors
•
Transfer rate exceeding best ATA (~150 MB/s) with scalability to higher
•
rates
Low pin count for both host and devices
•
AC'97 Audio Codec
Compliant with AC'97 2.3 specifications
•
Meets performance requirements for audio on PC99/2001 systems
•
Meets Microsoft WHQL/WLP 2.0 audio requirements
•
2
