Model:
PES1A, PESV1A
Manual:
Paper copy of this manual, PDF available
CD-ROM disc:
RealPort virtual COM port software for Windows 98/ME/2000/XP/NT 4.0
B&B discovery software (finder.exe)
PDF of PES1A/PESV1A User Manual
PDF of Quick Start guide
Operating Systems supported
Windows 98/ME/2000/XP/NT 4.0
(call B&B Tech Support for other operating systems)
Dimensions
PES1A – 0.8 x 1.7 x 3.9 in (2.0 x 4.2 x 9.8 cm)
PESV1A – 1.0 x 2.8 x 5.1 inches (2.5 x 7.1 x 13.0 cm)
Power Supply Requirements:
Class 3 Power over Ethernet (PoE)
Power Consumption:
Class 3 device for PoE configuration
Power Output (PESV1A only):
5, 9, or 12VDC @ 4W maximum, slide switch selectable
Connector is pluggable two position terminal block 125mA max in rush
Operating Temperature:
0 to 70 °C (32 to 158 °F)
Storage Temperature:
−40 to 85 °C (−40 to 185 °F)
Humidity:
10% to 90% R.H. non-condensing
Approvals:
CE, FCC, class B
Link Integrity Indicator:
Yellow LED (on Ethernet connector)
Activity Indicator:
Green LED (on Ethernet connector)
Ethernet Connector:
Single RJ-45 female (with built-in LED indicators)
Ethernet Standards Supported:
IEEE 802.3 10/100 Mbps auto-detecting, 10BaseT, 100BaseTX
IEEE 802.3af Power over Ethernet, compatibility for both data and spare
pair lines
Protocols Supported:
TCP, UDP, DHCP, SNMP, SSL/TLS, TELNET, RLOGIN, RFC 2217, LPD,
HTTP/HTTPS, SMTP, ICMP, IGMP, ARP
Serial Connector:
9 pin D-type male (DB-9M)
RS-232 Interface Lines Supported:
TD, RD, RTS, CTS, DTR, DSR, DCD, DSR, GND
Serial Data Rates:
50, 75, 110, 134, 150, 200, 300, 600, 1200, 1800, 2400, 4800, 9600,
14400, 19200, 28800, 38400, 57600, 115200, 230400 bps
Parity:
None, Even, Odd, Mark, Space
Manual Documentation Number: PES1A/PESV1A-4905m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Product Specifications
P
r
o
d
u
c
t
S
p
e
c
i
f
i
c
a
t
P
r
o
d
u
c
t
S
p
e
c
i
f
i
c
a
Product Specifications
i
o
n
s
t
i
o
n
s
TCP/UDP Forwarding Characteristics:
41
42
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Data Bits:
5, 6, 7 or 8
Stop Bits:
1, 2
Flow control:
None, Hardware, Software
Set-up Options:
Web Configuration and Management Interface
Configuration Modes:
Direct IP (TCP or UDP Sockets)
Virtual COM Port (RealPort)
Paired Mode (serial bridge/serial tunneling)
Terminal
Modem Emulation
Custom
Configuration Method:
Uses any web browser via built-in web server
Customizable web interface option with support for Java applets
Security:
Admin configuration password protection
Strong SSL v3.0 / TLS v1.0 based encryption – DES (56 bit), 3DES (168
bit), AES (128/256 bit)
Device Management:
SNMP – RFC 1213/1215/1316/131
IP Address Assignment:
Static IP, DHCP, Auto-IP
Bytes, Idle Time, Data Pattern
Event Notification:
Via email with SNMP traps triggered by matching data pattern
Accessories:
Panel mount bracket
Manual Documentation Number: PES1A/PESV1A-4905m
